3THZ

Human MutSbeta complexed with an IDL of 6 bases (Loop6) and ADP


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.30 Å
  • R-Value Free: 0.285
  • R-Value Work: 0.239
  • R-Value Observed: 0.241

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Mechanism of mismatch repair revealed by human MutS bound to unpaired DNA loops

Gupta, S.Gellert, M.Yang, W.

(2012) Nat Struct Mol Biol 19: 72-78

  • DOI: https://doi.org/10.1038/nsmb.2175
  • Primary Citation of Related Structures:
    3THW, 3THX, 3THY, 3THZ

  • PubMed Abstract:

    DNA mismatch repair corrects replication errors, thus reducing mutation rates and microsatellite instability. Genetic defects in this pathway cause Lynch syndrome and various cancers in humans. Binding of a mispaired or unpaired base by bacterial MutS and eukaryotic MutSα is well characterized. We report here crystal structures of human MutSβ in complex with DNA containing insertion-deletion loops (IDL) of two, three, four or six unpaired nucleotides. In contrast to eukaryotic MutSα and bacterial MutS, which bind the base of a mismatched nucleotide, MutSβ binds three phosphates in an IDL. DNA is severely bent at the IDL; unpaired bases are flipped out into the major groove and partially exposed to solvent. A normal downstream base pair can become unpaired; a single unpaired base can thereby be converted to an IDL of two nucleotides and recognized by MutSβ. The C-terminal dimerization domains form an integral part of the MutS structure and coordinate asymmetrical ATP hydrolysis by Msh2 and Msh3 with mismatch binding to signal for repair.


  • Organizational Affiliation

    Laboratory of Molecular Biology, National Institute of Diabetes and Digestive and Kidney Diseases, US National Institutes of Health, Bethesda, Maryland, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA mismatch repair protein Msh2934Homo sapiensMutation(s): 0
Gene Names: MSH2
UniProt & NIH Common Fund Data Resources
Find proteins for P43246 (Homo sapiens)
Explore P43246
Go to UniProtKB:  P43246
PHAROS:  P43246
GTEx:  ENSG00000095002
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP43246
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA mismatch repair protein Msh3918Homo sapiensMutation(s): 0
Gene Names: DUC1DUGMSH3
UniProt & NIH Common Fund Data Resources
Find proteins for P20585 (Homo sapiens)
Explore P20585
Go to UniProtKB:  P20585
PHAROS:  P20585
GTEx:  ENSG00000113318
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP20585
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains LengthOrganismImage
DNA Loop6 minus strandC [auth D]24N/A
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains LengthOrganismImage
DNA Loop6 plus strandD [auth E]28N/A
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP
Query on ADP

Download Ideal Coordinates CCD File
E [auth A]ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 4.30 Å
  • R-Value Free: 0.285
  • R-Value Work: 0.239
  • R-Value Observed: 0.241
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 103.68α = 90
b = 154.63β = 90
c = 161.59γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
CNSrefinement
Blu-Icedata collection
DENZOdata reduction
SCALEPACKdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

  • Released Date: 2011-12-21
  • Deposition Author(s): Yang, W.

Revision History  (Full details and data files)

  • Version 1.0: 2011-12-21
    Type: Initial release
  • Version 1.1: 2013-06-26
    Changes: Database references
  • Version 1.2: 2019-07-17
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
