4LX0

Crystal structure of Myo5b globular tail domain in complex with active Rab11a


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.181
  • R-Value Observed: 0.183

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structural basis of myosin V Rab GTPase-dependent cargo recognition.

Pylypenko, O.Attanda, W.Gauquelin, C.Lahmani, M.Coulibaly, D.Baron, B.Hoos, S.Titus, M.A.England, P.Houdusse, A.M.

(2013) Proc Natl Acad Sci U S A 110: 20443-20448

  • DOI: https://doi.org/10.1073/pnas.1314329110
  • Primary Citation of Related Structures:
    4LWZ, 4LX0, 4LX1, 4LX2

  • PubMed Abstract:

    Specific recognition of the cargo that molecular motors transport or tether to cytoskeleton tracks allows them to perform precise cellular functions at particular times and positions in cells. However, very little is known about how evolution has favored conservation of functions for some isoforms, while also allowing for the generation of new recognition sites and specialized cellular functions. Here we present several crystal structures of the myosin Va or the myosin Vb globular tail domain (GTD) that gives insights into how the motor is linked to the recycling membrane compartments via Rab11 or to the melanosome membrane via recognition of the melanophilin adaptor that binds to Rab27a. The structures illustrate how the Rab11-binding site has been conserved during evolution and how divergence at another site of the GTD allows more specific interactions such as the specific recognition of melanophilin by the myosin Va isoform. With atomic structural insights, these structures also show how either the partner or the GTD structural plasticity upon association is critical for selective recruitment of the motor.


  • Organizational Affiliation

    Structural Motility, Institut Curie, 75248 Paris Cedex 05, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Ras-related protein Rab-11A
A, C
177Homo sapiensMutation(s): 0
Gene Names: RAB11ARAB11
EC: 3.6.5.2
UniProt & NIH Common Fund Data Resources
Find proteins for P62491 (Homo sapiens)
Explore P62491
Go to UniProtKB:  P62491
PHAROS:  P62491
GTEx:  ENSG00000103769
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP62491
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Unconventional myosin-Vb
B, D
427Homo sapiensMutation(s): 0
Gene Names: MYO5BKIAA1119
UniProt & NIH Common Fund Data Resources
Find proteins for Q9ULV0 (Homo sapiens)
Explore Q9ULV0
Go to UniProtKB:  Q9ULV0
PHAROS:  Q9ULV0
GTEx:  ENSG00000167306
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9ULV0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GDP
Query on GDP

Download Ideal Coordinates CCD File
G [auth A],
K [auth C]
GUANOSINE-5'-DIPHOSPHATE
C10 H15 N5 O11 P2
QGWNDRXFNXRZMB-UUOKFMHZSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
H [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
BEF
Query on BEF

Download Ideal Coordinates CCD File
F [auth A],
J [auth C]
BERYLLIUM TRIFLUORIDE ION
Be F3
OGIAHMCCNXDTIE-UHFFFAOYSA-K
MG
Query on MG

Download Ideal Coordinates CCD File
E [auth A],
I [auth C]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.19 Å
  • R-Value Free: 0.218
  • R-Value Work: 0.181
  • R-Value Observed: 0.183
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 95.1α = 90
b = 125.92β = 90
c = 157.66γ = 90
Software Package:
Software NamePurpose
DNAdata collection
MOLREPphasing
PHENIXrefinement
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2013-11-20
    Type: Initial release
  • Version 1.1: 2013-12-18
    Changes: Database references
  • Version 1.2: 2013-12-25
    Changes: Derived calculations
  • Version 1.3: 2014-01-15
    Changes: Database references
  • Version 1.4: 2024-02-28
    Changes: Data collection, Database references, Derived calculations
