5BPN

Crystal structure of nucleotide-free human Hsp70 NBD double mutant E268Q+R272K.

• PDB DOI: https://doi.org/10.2210/pdb5BPN/pdb

• Classification: HYDROLASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2015-05-28 Released: 2016-09-14
• Deposition Author(s): Narayanan, D., Engh, R.A.
• Funding Organization(s): FRINAT

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.261
• R-Value Work: 0.216
• R-Value Observed: 0.220

Starting Model: experimental

Literature

Nucleotide binding to variants of the HSP70-NBD.

Narayanan, D., Pflug, A., Christopeit, T., Kyomuhendo, P., Engh, R.A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 43.08 kDa
• Atom Count: 2,950
• Modelled Residue Count: 372
• Deposited Residue Count: 388
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Heat shock 70 kDa protein 1A	A	388	Homo sapiens	Mutation(s): 2  Gene Names: HSPA1A, HSPA1, HSX70
UniProt & NIH Common Fund Data Resources
Find proteins for P0DMV8 (Homo sapiens) Explore P0DMV8  Go to UniProtKB:  P0DMV8
PHAROS:  P0DMV8 GTEx:  ENSG00000204389

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
TRS	E [auth A]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C4 H12 N O3 LENZDBCJOHFCAS-UHFFFAOYSA-O
PO4	C [auth A], D [auth A]	PHOSPHATE ION O4 P NBIIXXVUZAFLBC-UHFFFAOYSA-K
CL	B [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free: 0.261
• R-Value Work: 0.216
• R-Value Observed: 0.220
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 45.85	α = 90
b = 83.348	β = 90
c = 98.889	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Coot	model building
MOLREP	phasing
Aimless	data scaling
XDS	data reduction

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2016-09-14
Deposition Author(s): Narayanan, D., Engh, R.A.

---

Funding Organization	Location	Grant Number
FRINAT	Norway	191303

Revision History

• Version 1.0: 2016-09-14
  Type: Initial release

• Version 1.1: 2024-01-10
  Changes: Data collection, Database references, Refinement description
