5FAZ

Crystal structure of the Q108K:K40L:T51V mutant of human Cellular Retinol Binding Protein II in complex with All-trans-Retinal after 24 hours of incubation at 1.4 Angstrom Resolution

• PDB DOI: https://doi.org/10.2210/pdb5FAZ/pdb

• Classification: TRANSPORT PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21
• Mutation(s): Yes


• Deposited: 2015-12-13 Released: 2016-12-14
• Deposition Author(s): Nosrati, M., Nossoni, Z., Geiger, J.H.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free: 0.255
• R-Value Work: 0.216
• R-Value Observed: 0.218

Starting Model: experimental

Literature

Crystal structure of the Q108K:K40L:T51V mutant of human Cellular Retinol Binding Protein II in complex with All-trans-Retinal after 24 hours of incubation at 1.54 Angstrom Resolution

Nossoni, Z., Nosrati, M., Wang, W., Berbasova, T., Vasileiou, C., Borhan, B., Geiger, J.H.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 31.85 kDa
• Atom Count: 2,562
• Modelled Residue Count: 266
• Deposited Residue Count: 266
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Retinol-binding protein 2	A, B	133	Homo sapiens	Mutation(s): 3  Gene Names: RBP2, CRBP2
UniProt & NIH Common Fund Data Resources
Find proteins for P50120 (Homo sapiens) Explore P50120  Go to UniProtKB:  P50120
PHAROS:  P50120 GTEx:  ENSG00000114113

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
RET	D [auth A], F [auth B]	RETINAL C20 H28 O NCYCYZXNIZJOKI-OVSJKPMPSA-N
ACT	C [auth A], E [auth B]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free: 0.255
• R-Value Work: 0.216
• R-Value Observed: 0.218
• Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 29.898	α = 87.17
b = 36.323	β = 92.48
c = 63.987	γ = 115.28

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2016-12-14
Deposition Author(s): Nosrati, M., Nossoni, Z., Geiger, J.H.

Revision History

• Version 1.0: 2016-12-14
  Type: Initial release

• Version 1.1: 2023-09-27
  Changes: Data collection, Database references, Refinement description
• Version 1.2: 2024-10-23
  Changes: Structure summary
