5HDN

Crystal structure of heat shock factor1-DBD complex with ds-DNA and TtT


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free: 0.202
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

HSF1-DBD crystal structure

Feng, H.Liu, W.Wang, D.C.

To be published.

Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Heat shock factor protein 1A,
B,
E [auth C],
F [auth D]
112Homo sapiensMutation(s): 0
Gene Names: HSF1HSTF1
UniProt & NIH Common Fund Data Resources
Find proteins for Q00613 (Homo sapiens)
Explore Q00613
Go to UniProtKB:  Q00613
PHAROS:  Q00613
GTEx:  ENSG00000185122
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ00613
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(*GP*GP*TP*TP*CP*TP*AP*GP*AP*AP*CP*C)-3')C [auth E],
D [auth F],
G,
H
12Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.68 Å
  • R-Value Free: 0.202
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.415α = 90
b = 127.367β = 100.55
c = 55.268γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XSCALEdata reduction
XDSdata scaling
XDSphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-01-11
    Type: Initial release
  • Version 1.1: 2017-09-27
    Changes: Data collection
  • Version 1.2: 2023-11-08
    Changes: Data collection, Database references, Refinement description
