5KIC

Long-sought stabilization of berkelium(IV) in solution: An anomaly within the heavy actinide series


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.205
  • R-Value Observed: 0.207

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Chelation and stabilization of berkelium in oxidation state +IV.

Deblonde, G.J.Sturzbecher-Hoehne, M.Rupert, P.B.An, D.D.Illy, M.C.Ralston, C.Y.Brabec, J.de Jong, W.A.Strong, R.K.Abergel, R.J.

(2017) Nat Chem 9: 843-849

  • DOI: https://doi.org/10.1038/nchem.2759
  • Primary Citation of Related Structures:
    5KIC

  • PubMed Abstract:

    Berkelium (Bk) has been predicted to be the only transplutonium element able to exhibit both +III and +IV oxidation states in solution, but evidence of a stable oxidized Bk chelate has so far remained elusive. Here we describe the stabilization of the heaviest 4+ ion of the periodic table, under mild aqueous conditions, using a siderophore derivative. The resulting Bk(IV) complex exhibits luminescence via sensitization through an intramolecular antenna effect. This neutral Bk(IV) coordination compound is not sequestered by the protein siderocalin-a mammalian metal transporter-in contrast to the negatively charged species obtained with neighbouring trivalent actinides americium, curium and californium (Cf). The corresponding Cf(III)-ligand-protein ternary adduct was characterized by X-ray diffraction analysis. Combined with theoretical predictions, these data add significant insight to the field of transplutonium chemistry, and may lead to innovative Bk separation and purification processes.


  • Organizational Affiliation

    Chemical Sciences Division, Lawrence Berkeley National Laboratory, Berkeley, California 94720, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Neutrophil gelatinase-associated lipocalin
A, B, C
180Homo sapiensMutation(s): 0
Gene Names: LCN2HNLNGAL
UniProt & NIH Common Fund Data Resources
Find proteins for P80188 (Homo sapiens)
Explore P80188
Go to UniProtKB:  P80188
PHAROS:  P80188
GTEx:  ENSG00000148346
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP80188
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
4OL
Query on 4OL

Download Ideal Coordinates CCD File
E [auth A],
H [auth B],
K [auth C]
N,N'-butane-1,4-diylbis[1-hydroxy-N-(3-{[(1-hydroxy-6-oxo-1,6-dihydropyridin-2-yl)carbonyl]amino}propyl)-6-oxo-1,6-dihydropyridine-2-carboxamide]
C34 H38 N8 O12
KUWKQASGHNTJAT-UHFFFAOYSA-N
CF
Query on CF

Download Ideal Coordinates CCD File
D [auth A],
G [auth B],
J [auth C]
CALIFORNIUM ION
Cf
NJOOSZZTDCOTJQ-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
M [auth C],
N [auth C],
O [auth C]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
CL
Query on CL

Download Ideal Coordinates CCD File
F [auth A],
I [auth B],
L [auth C]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.70 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.205
  • R-Value Observed: 0.207
  • Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 119.574α = 90
b = 119.574β = 90
c = 108.839γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
HKL-2000data reduction
SCALEPACKdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2017-04-26
    Type: Initial release
  • Version 1.1: 2017-05-10
    Changes: Database references
  • Version 1.2: 2017-09-06
    Changes: Database references
  • Version 1.3: 2023-09-27
    Changes: Data collection, Database references, Refinement description
  • Version 1.4: 2024-10-23
    Changes: Structure summary
