5M9O

Crystal structure of human SND1 extended Tudor domain in complex with a symmetrically dimethylated E2F peptide

PDB DOI: https://doi.org/10.2210/pdb5M9O/pdb

Classification: TRANSCRIPTION
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2016-11-01 Released: 2016-12-07
Deposition Author(s): Tallant, C., Savitsky, P., Moehlenbrink, J., Chan, C., Nunez-Alonso, G., Siejka, P., Sorrell, F.J., von Delft, F., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Fedorov, O., La Thangue, N.B., Knapp, S., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free: 0.261
R-Value Work: 0.229
R-Value Observed: 0.230

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.3 of the entry. See complete history.

Literature

Crystal structure of human SND1 extended Tudor domain in complex with a symmetrically dimethylated E2F peptide

Tallant, C., Savitsky, P., Moehlenbrink, J., Chan, C., Nunez-Alonso, G., Siejka, P., Sorrell, F.J., von Delft, F., Arrowsmith, C.H., Edwards, A.M., Bountra, C., Fedorov, O., La Thangue, N.B., Knapp, S.

To be published.

Macromolecule Content

Total Structure Weight: 26.39 kDa
Atom Count: 1,921
Modelled Residue Count: 220
Deposited Residue Count: 233
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Staphylococcal nuclease domain-containing protein 1	A	224	Homo sapiens	Mutation(s): 0 Gene Names: SND1, TDRD11 EC: 3.1.31.1
UniProt & NIH Common Fund Data Resources
Find proteins for Q7KZF4 (Homo sapiens) Explore Q7KZF4 Go to UniProtKB: Q7KZF4
PHAROS: Q7KZF4 GTEx: ENSG00000197157
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q7KZF4
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
E2F peptide	B	9	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q01094 (Homo sapiens) Explore Q01094 Go to UniProtKB: Q01094
PHAROS: Q01094 GTEx: ENSG00000101412
Entity Groups
UniProt Group	Q01094
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
2MR Query on 2MR	B	L-PEPTIDE LINKING	C₈ H₁₈ N₄ O₂		ARG

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free: 0.261
R-Value Work: 0.229
R-Value Observed: 0.230
Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 36.243	α = 90
b = 80.626	β = 90.38
c = 39.289	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2016-12-07

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2016-12-07
Type: Initial release
Version 1.1: 2016-12-14
Changes: Derived calculations
Version 1.2: 2024-01-17
Changes: Data collection, Database references, Refinement description
Version 1.3: 2024-11-06
Changes: Structure summary
