5RHA

PanDDA analysis group deposition SARS-CoV-2 main protease fragment screen -- Crystal Structure of SARS-CoV-2 main protease in complex with Z147647874 (Mpro-x2779)

• PDB DOI: https://doi.org/10.2210/pdb5RHA/pdb
• Deposition Group: G_1002155 (changed state) ExploreG_1002155

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2020-05-15 Released: 2020-05-27
• Deposition Author(s): Fearon, D., Owen, C.D., Douangamath, A., Lukacik, P., Powell, A.J., Strain-Damerell, C.M., Resnick, E., Krojer, T., Gehrtz, P., Wild, C., Aimon, A., Brandao-Neto, J., Carbery, A., Dunnett, L., Skyner, R., Snee, M., London, N., Walsh, M.A., von Delft, F.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.51 Å
• R-Value Free: 0.209
• R-Value Work: 0.173
• R-Value Observed: 0.175

Literature

PanDDA analysis group deposition SARS-CoV-2 main protease fragment screen

Fearon, D., Owen, C.D., Douangamath, A., Lukacik, P., Powell, A.J., Strain-Damerell, C.M., Resnick, E., Krojer, T., Gehrtz, P., Wild, C., Aimon, A., Brandao-Neto, J., Carbery, A., Dunnett, L., Skyner, R., Snee, M., London, N., Walsh, M.A., von Delft, F.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 34.36 kDa
• Atom Count: 2,740
• Modelled Residue Count: 304
• Deposited Residue Count: 306
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
3C-like proteinase	A	306	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
T8M (Subject of Investigation/LOI)	B [auth A]	1-{4-[(thiophen-2-yl)methyl]piperazin-1-yl}ethan-1-one C11 H16 N2 O S PEHVQKQLQOREKN-UHFFFAOYSA-N
DMS	C [auth A], D [auth A], E [auth A], F [auth A]	DIMETHYL SULFOXIDE C2 H6 O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.51 Å
• R-Value Free: 0.209
• R-Value Work: 0.173
• R-Value Observed: 0.175
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 112.449	α = 90
b = 52.773	β = 103.02
c = 44.515	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
REFMAC	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2020-05-27
Deposition Author(s): Fearon, D., Owen, C.D., Douangamath, A., Lukacik, P., Powell, A.J., Strain-Damerell, C.M., Resnick, E., Krojer, T., Gehrtz, P., Wild, C., Aimon, A., Brandao-Neto, J., Carbery, A., Dunnett, L., Skyner, R., Snee, M., London, N., Walsh, M.A., von Delft, F.

Revision History

• Version 1.0: 2020-05-27
  Type: Initial release
