5TOL

CRYSTAL STRUCTURE OF BETA-SITE APP-CLEAVING ENZYME 1 COMPLEXED WITH N-(3-((4AS,7AS)-2-AMINO-4,4A,5,6-TETRAHYDRO-7AH-FURO[2,3-D][1,3]THIAZIN-7A-YL)-4-FLUOROPHENYL)-5-BROMO-2-PYRIDINECARBOXAMIDE


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.51 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.201
  • R-Value Observed: 0.204

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Discovery of furo[2,3-d][1,3]thiazinamines as beta amyloid cleaving enzyme-1 (BACE1) inhibitors.

Wu, Y.J.Guernon, J.Rajamani, R.Toyn, J.H.Ahlijanian, M.K.Albright, C.F.Muckelbauer, J.Chang, C.Camac, D.Macor, J.E.Thompson, L.A.

(2016) Bioorg Med Chem Lett 26: 5729-5731

  • DOI: https://doi.org/10.1016/j.bmcl.2016.10.055
  • Primary Citation of Related Structures:
    5TOL

  • PubMed Abstract:

    This Letter describes the synthesis and structure-activity relationships of a series of furo[2,3-d][1,3]thiazinamine BACE1 inhibitors. The co-crystal structure of a representative thiazinamine 2e bound with the BACE1 active site displayed a binding mode driven by interactions with the catalytic aspartate dyad and engagement of the biaryl amide toward the S1 and S3 pockets. This work indicates that furo[2,3-d]thiazine can serve as a viable bioisostere of the known furo[3,4-d]thiazine.


  • Organizational Affiliation

    Research and Development, Bristol-Myers Squibb, 5 Research Parkway, Wallingford, CT 06492, USA. Electronic address: Yong-Jin.Wu@bms.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Beta-secretase 1412Homo sapiensMutation(s): 2
Gene Names: BACE1BACEKIAA1149
EC: 3.4.23.46
UniProt & NIH Common Fund Data Resources
Find proteins for P56817 (Homo sapiens)
Explore P56817
Go to UniProtKB:  P56817
PHAROS:  P56817
GTEx:  ENSG00000186318
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP56817
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
7H3
Query on 7H3

Download Ideal Coordinates CCD File
B [auth A]N-{3-[(4aR,7aR)-2-amino-4,4a,5,6-tetrahydro-7aH-furo[2,3-d][1,3]thiazin-7a-yl]-4-fluorophenyl}-5-bromopyridine-2-carboxamide
C18 H16 Br F N4 O2 S
DACRJCISVSMZQT-XTZNXHDOSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.51 Å
  • R-Value Free: 0.257
  • R-Value Work: 0.201
  • R-Value Observed: 0.204
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 101.49α = 90
b = 101.49β = 90
c = 171.237γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
SCALAdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-11-23
    Type: Initial release
  • Version 1.1: 2016-12-07
    Changes: Database references
  • Version 1.2: 2024-11-06
    Changes: Data collection, Database references, Structure summary
