5YY1 | pdb_00005yy1

Co-crystal Structure of KRAS (G12C) covalently bound with Quinazoline based inhibitor JBI739

PDB DOI: https://doi.org/10.2210/pdb5YY1/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2017-12-07 Released: 2018-04-18
Deposition Author(s): Swaminathan, S., Thakur, M.K., Kandan, S., Gautam, A., Kanavalli, M., Simhadri, P., Gosu, R.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.69 Å
R-Value Free:
0.235 (Depositor), 0.245 (DCC)
R-Value Work:
0.197 (Depositor), 0.206 (DCC)
R-Value Observed:
0.199 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Co-crystal Structure of KRAS (G12C) covalently bound with Quinazoline based inhibitor JBI739

Swaminathan, S., Thakur, M.K., Kandan, S., Gautam, A., Kanavalli, M., Simhadri, P., Gosu, R.

To be published.

Macromolecule Content

Total Structure Weight: 20.41 kDa
Atom Count: 1,563
Modeled Residue Count: 170
Deposited Residue Count: 170
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GTPase KRas	A	170	Homo sapiens	Mutation(s): 4 Gene Names: KRAS, KRAS2, RASK2 EC: 3.6.5.2
UniProt & NIH Common Fund Data Resources
Find proteins for P01116 (Homo sapiens) Explore P01116 Go to UniProtKB: P01116
PHAROS: P01116 GTEx: ENSG00000133703
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P01116
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 4 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
94F Query on 94F Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	1-[4-[6-chloranyl-8-fluoranyl-7-[2-(trifluoromethyl)phenyl]quinazolin-4-yl]piperazin-1-yl]propan-1-one C₂₂ H₁₉ Cl F₄ N₄ O IIOXYCBQJCNGFW-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
GDP Query on GDP Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	GUANOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₁ P₂ QGWNDRXFNXRZMB-UUOKFMHZSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A]	E [auth A], F [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.69 Å
R-Value Free: 0.235 (Depositor), 0.245 (DCC)
R-Value Work: 0.197 (Depositor), 0.206 (DCC)
R-Value Observed: 0.199 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 40.391	α = 90
b = 51.73	β = 90
c = 89.242	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2018-04-18

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-04-18
Type: Initial release
Version 1.1: 2023-11-22
Changes: Data collection, Database references, Derived calculations, Refinement description, Structure summary
Version 1.2: 2024-11-13
Changes: Structure summary
