6ENH

Crystal structure of the 43K ATPase domain of Thermus thermophilus gyrase B in complex with an aminocoumarin

• PDB DOI: https://doi.org/10.2210/pdb6ENH/pdb

• Classification: ISOMERASE
• Organism(s): Thermus thermophilus HB8
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-10-04 Released: 2019-04-10
• Deposition Author(s): Vanden Broeck, A., McEwen, A.G., Lamour, V.
• Funding Organization(s): French National Research Agency

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.94 Å
• R-Value Free: 0.233
• R-Value Work: 0.197
• R-Value Observed: 0.199

Starting Model: experimental

Literature

Structural Basis for DNA Gyrase Interaction with Coumermycin A1.

Vanden Broeck, A., McEwen, A.G., Chebaro, Y., Potier, N., Lamour, V.

(2019) J Med Chem 62: 4225-4231

• PubMed: 30920824
• DOI: https://doi.org/10.1021/acs.jmedchem.8b01928
• Primary Citation of Related Structures:
  6ENG, 6ENH


• PubMed Abstract:


  Coumermycin A1 is a natural aminocoumarin that inhibits bacterial DNA gyrase, a member of the GHKL proteins superfamily. We report here the first cocrystal structures of gyrase B bound to coumermycin A1, revealing that one coumermycin A1 molecule traps simultaneously two ATP-binding sites. The inhibited dimers from different species adopt distinct sequence-dependent conformations, alternative to the ATP-bound form. These structures provide a basis for the rational development of coumermycin A1 derivatives for antibiotherapy and biotechnology applications.

---

Organizational Affiliation:

Integrated Structural Biology Department, IGBMC, UMR7104 CNRS, U1258 Inserm, University of Strasbourg, Illkirch 67404 , France.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: SAXS, gel filtration, mass spectrometry

Macromolecule Content

• Total Structure Weight: 44.25 kDa
• Atom Count: 3,008
• Modelled Residue Count: 366
• Deposited Residue Count: 393
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA gyrase subunit B	A	393	Thermus thermophilus HB8	Mutation(s): 0  Gene Names: gyrB, TTHA1586 EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for Q5SHZ4 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SHZ4  Go to UniProtKB:  Q5SHZ4

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
BHW	B [auth A]	Coumermycin A1 C55 H59 N5 O20 WTIJXIZOODAMJT-DHFGXMAYSA-N
IMD	C [auth A], D [auth A]	IMIDAZOLE C3 H5 N2 RAXXELZNTBOGNW-UHFFFAOYSA-O

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.94 Å
• R-Value Free: 0.233
• R-Value Work: 0.197
• R-Value Observed: 0.199
• Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 166.37	α = 90
b = 37.85	β = 110.24
c = 66.75	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
XSCALE	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2019-04-10
Deposition Author(s): Vanden Broeck, A., McEwen, A.G., Lamour, V.

---

Funding Organization	Location	Grant Number
French National Research Agency	France	ANR-10-INSB-05-01
French National Research Agency	France	ANR-10-LABX-0030-INRT

Revision History

• Version 1.0: 2019-04-10
  Type: Initial release

• Version 1.1: 2019-05-08
  Changes: Data collection, Database references
• Version 1.2: 2024-01-17
  Changes: Data collection, Database references, Refinement description
