6H2Z

The crystal structure of human carbonic anhydrase II in complex with 4-(4-phenylpiperidine-1-carbonyl)benzenesulfonamide.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.94 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.179
  • R-Value Observed: 0.181

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Exploring structural properties of potent human carbonic anhydrase inhibitors bearing a 4-(cycloalkylamino-1-carbonyl)benzenesulfonamide moiety.

Buemi, M.R.Di Fiore, A.De Luca, L.Angeli, A.Mancuso, F.Ferro, S.Monti, S.M.Buonanno, M.Russo, E.De Sarro, G.De Simone, G.Supuran, C.T.Gitto, R.

(2018) Eur J Med Chem 163: 443-452

  • DOI: https://doi.org/10.1016/j.ejmech.2018.11.073
  • Primary Citation of Related Structures:
    6H2Z, 6H33, 6H34, 6H36, 6H37, 6H38

  • PubMed Abstract:

    Guided by the crystal structure of 4-(3,4-dihydroquinolin-1(2H)-ylcarbonyl)benzenesulfonamide 3 in complex with hCA II (PDB code 4Z0Q), a novel series of cycloalkylamino-1-carbonylbenzenesulfonamides was designed and synthesized. Thus, we replaced the quinoline ring with an azepine/piperidine/piperazine nucleus and introduced further modifications on cycloalkylamine nucleus by means the installation of hydrophobic/hydrophilic functionalities able to establish additional contacts in the middle area of the enzyme cavity. Among the synthesized compounds, the derivatives 7a, 7b, 8b exhibited a remarkable inhibition for hCA II and the brain-expressed hCA VII in subnanomolar range. The binding of these molecules to the target enzymes was characterized by means of a crystallographic analysis, providing a clear snapshot of the most important interactions established by this class of inhibitors into the hCA II and hCA VII catalytic site. Notably, our results showed that the benzylpiperazine tail of compound 8b is oriented both in hCA II and in hCA VII toward a poorly explored region of the active site. These features should be further investigated for the design of new isoform selective CA inhibitors.


  • Organizational Affiliation

    Dipartimento di Scienze Chimiche, Biologiche, Farmaceutiche ed Ambientali (CHIBIOFARAM), Università degli Studi di Messina, Viale Palatucci, Polo didattico SS, Annunziata, 98168, Messina, Italy.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Carbonic anhydrase 2262Homo sapiensMutation(s): 0
Gene Names: CA2
EC: 4.2.1.1 (PDB Primary Data), 4.2.1.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P00918 (Homo sapiens)
Explore P00918
Go to UniProtKB:  P00918
PHAROS:  P00918
GTEx:  ENSG00000104267
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00918
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.94 Å
  • R-Value Free: 0.214
  • R-Value Work: 0.179
  • R-Value Observed: 0.181
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.35α = 90
b = 41.11β = 104.22
c = 71.67γ = 90
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
CNSphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2018-12-19
    Type: Initial release
  • Version 1.1: 2024-01-17
    Changes: Data collection, Database references, Refinement description
