9C8A

Minimal PutA proline dehydrogenase domain (design #2) with the FAD N5 modified with propanal resulting from inactivation with N-allylglycine(replicate #1)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.54 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.169
  • R-Value Observed: 0.170

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Noncovalent Inhibition and Covalent Inactivation of Proline Dehydrogenase by Analogs of N -Propargylglycine.

Tanner, J.J.Ji, J.Bogner, A.N.Scott, G.K.Patel, S.M.Seravalli, J.Gates, K.S.Benz, C.C.Becker, D.F.

(2024) Biochemistry

  • DOI: https://doi.org/10.1021/acs.biochem.4c00429
  • Primary Citation of Related Structures:
    8UPZ, 8UQ0, 8UQ1, 9C8A, 9C8B, 9C8C

  • PubMed Abstract:

    The flavoenzyme proline dehydrogenase (PRODH) catalyzes the first step of proline catabolism, the oxidation of l-proline to Δ 1 -pyrroline-5-carboxylate. The enzyme is a target for chemical probe discovery because of its role in the metabolism of certain cancer cells. N -propargylglycine is the first and best characterized mechanism-based covalent inactivator of PRODH. This compound consists of a recognition module (glycine) that directs the inactivator to the active site and an alkyne warhead that reacts with the FAD after oxidative activation, leading to covalent modification of the FAD N5 atom. Here we report structural and kinetic data on analogs of N -propargylglycine with the goals of understanding the initial docking step of the inactivation mechanism and to test the allyl group as a warhead. The crystal structures of PRODH complexed with unreactive analogs in which N is replaced by S show how the recognition module mimics the substrate proline by forming ion pairs with conserved arginine and lysine residues. Further, the C atom adjacent to the alkyne warhead is optimally positioned for hydride transfer to the FAD, providing the structural basis for the first bond-breaking step of the inactivation mechanism. The structures also suggest new strategies for designing improved N -propargylglycine analogs. N -allylglycine, which consists of a glycine recognition module and allyl warhead, is shown to be a covalent inactivator; however, it is less efficient than N -propargylglycine in both enzyme inactivation and cellular assays. Crystal structures of the N -allylglycine-inactivated enzyme are consistent with covalent modification of the N5 by propanal.


  • Organizational Affiliation

    Department of Biochemistry, University of Missouri, Columbia, Missouri 65211, United States.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bifunctional protein PutA
A, B
396Sinorhizobium meliloti SM11Mutation(s): 0
Gene Names: putASM11_chr0102
EC: 1.5.5.2 (PDB Primary Data), 1.2.1.88 (PDB Primary Data)
UniProt
Find proteins for F7X6I3 (Sinorhizobium meliloti (strain SM11))
Explore F7X6I3
Go to UniProtKB:  F7X6I3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF7X6I3
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.54 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.169
  • R-Value Observed: 0.170
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 48.943α = 104.29
b = 55.099β = 100.38
c = 76.057γ = 108.61
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data

  • Released Date: 2024-10-30
  • Deposition Author(s): Tanner, J.J.

Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United States1R01GM132640

Revision History  (Full details and data files)

  • Version 1.0: 2024-10-30
    Type: Initial release
