10PH | pdb_000010ph

Structure of the R. denitrificans GapR in the dimer-of-dimers form

PDB DOI: https://doi.org/10.2210/pdb10PH/pdb

Classification: DNA BINDING PROTEIN
Organism(s): Roseobacter denitrificans OCh 114
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2026-01-30 Released: 2026-09-30
Deposition Author(s): Schumacher, M.A.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.94 Å
R-Value Free:
0.262 (Depositor), 0.264 (DCC)
R-Value Work:
0.237 (Depositor), 0.243 (DCC)
R-Value Observed:
0.240 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 10PH

This is version 1.0 of the entry. See complete history.

Literature

Structure of the R. denitrificans GapR in the dimer-of-dimers form

Schumacher, M.A.

To be published.

Macromolecule Content

Total Structure Weight: 12.05 kDa
Atom Count: 621
Modeled Residue Count: 76
Deposited Residue Count: 103
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
UPF0335 protein RD1_2835	A	103	Roseobacter denitrificans OCh 114	Mutation(s): 0 Gene Names: RD1_2835
UniProt
Find proteins for Q165I2 (Roseobacter denitrificans (strain ATCC 33942 / OCh 114)) Explore Q165I2 Go to UniProtKB: Q165I2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q165I2
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.94 Å
R-Value Free: 0.262 (Depositor), 0.264 (DCC)
R-Value Work: 0.237 (Depositor), 0.243 (DCC)
R-Value Observed: 0.240 (Depositor)

Space Group: I 2 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 37.261	α = 90
b = 63.037	β = 90
c = 84.301	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHENIX	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-09-30

Deposition Author(s):

Schumacher, M.A.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R35GM13029

Revision History (Full details and data files)

Version 1.0: 2026-09-30
Type: Initial release
