10PQ | pdb_000010pq

Crystal structure of bovine ALDH3A1 H290L mutant - apo form

PDB DOI: https://doi.org/10.2210/pdb10PQ/pdb

Classification: OXIDOREDUCTASE
Organism(s): Bos taurus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2026-01-30 Released: 2026-09-02
Deposition Author(s): Hsu, N., Saleh, S., Kim, J., Li, H., Qiao, F.
Funding Organization(s): National Science Foundation (NSF, United States)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free:
0.201 (Depositor), 0.201 (DCC)
R-Value Work:
0.172 (Depositor), 0.172 (DCC)
R-Value Observed:
0.173 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 10PQ

This is version 1.0 of the entry. See complete history.

Literature

A Sequence Motif Enables Widespread Use of Non-Canonical Redox Cofactors in Natural Enzymes

Saleh, S., Hsu, N.

To be published.

Macromolecule Content

Total Structure Weight: 100.82 kDa
Atom Count: 7,852
Modeled Residue Count: 900
Deposited Residue Count: 904
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Aldehyde dehydrogenase	A, B	452	Bos taurus	Mutation(s): 1 Gene Names: ALDH3A1
UniProt
Find proteins for F1N015 (Bos taurus) Explore F1N015 Go to UniProtKB: F1N015
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	F1N015
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free: 0.201 (Depositor), 0.201 (DCC)
R-Value Work: 0.172 (Depositor), 0.172 (DCC)
R-Value Observed: 0.173 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.626	α = 77.22
b = 59.347	β = 79.81
c = 87.702	γ = 69.31

Software Package:

Software Name	Purpose
PHENIX	refinement
autoPROC	data reduction
autoPROC	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-09-02

Deposition Author(s):

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	2328145

Revision History (Full details and data files)

Version 1.0: 2026-09-02
Type: Initial release
