1G5M

HUMAN BCL-2, ISOFORM 1


Experimental Data Snapshot

  • Method: SOLUTION NMR
  • Conformers Submitted:

wwPDB Validation   3D Report Full Report

Currently 1G5M does not have a validation slider image.


This is version 1.4 of the entry. See complete history


Literature

Solution structure of the antiapoptotic protein bcl-2.

Petros, A.M.Medek, A.Nettesheim, D.G.Kim, D.H.Yoon, H.S.Swift, K.Matayoshi, E.D.Oltersdorf, T.Fesik, S.W.

(2001) Proc Natl Acad Sci U S A 98: 3012-3017

  • DOI: https://doi.org/10.1073/pnas.041619798
  • Primary Citation of Related Structures:
    1G5M, 1GJH

  • PubMed Abstract:

    The structures of two isoforms of Bcl-2 that differ by two amino acids have been determined by NMR spectroscopy. Because wild-type Bcl-2 behaved poorly in solution, the structures were determined by using Bcl-2/Bcl-x(L) chimeras in which part of the putative unstructured loop of Bcl-2 was replaced with a shortened loop from Bcl-x(L). These chimeric proteins have a low pI compared with the wild-type protein and are soluble. The structures of the two Bcl-2 isoforms consist of 6 alpha-helices with a hydrophobic groove on the surface similar to that observed for the homologous protein, Bcl-x(L). Comparison of the Bcl-2 structures to that of Bcl-x(L) shows that although the overall fold is the same, there are differences in the structural topology and electrostatic potential of the binding groove. Although the structures of the two isoforms of Bcl-2 are virtually identical, differences were observed in the ability of the proteins to bind to a 25-residue peptide from the proapoptotic Bad protein and a 16-residue peptide from the proapoptotic Bak protein. These results suggest that there are subtle differences in the hydrophobic binding groove in Bcl-2 that may translate into differences in antiapoptotic activity for the two isoforms.


  • Organizational Affiliation

    Pharmaceutical Discovery Division, Abbott Laboratories, Abbott Park, IL 60064, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
PROTEIN (APOPTOSIS REGULATOR BCL-2 WITH PUTATIVE FLEXIBLE LOOP REPLACED WITH A PORTION OF APOPTOSIS REGULATOR BCL-X PROTEIN)166Homo sapiensMutation(s): 2
Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for P10415 (Homo sapiens)
Explore P10415
Go to UniProtKB:  P10415
PHAROS:  P10415
GTEx:  ENSG00000171791
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP10415
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: SOLUTION NMR
  • Conformers Submitted:

Structure Validation

View Full Validation Report

Currently 1G5M does not have a validation slider image.



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2001-03-21
    Type: Initial release
  • Version 1.1: 2008-04-27
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2022-02-23
    Changes: Data collection, Database references, Derived calculations
  • Version 1.4: 2022-12-21
    Changes: Database references
