1OT7

Structural Basis for 3-deoxy-CDCA Binding and Activation of FXR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.233
  • R-Value Observed: 0.233

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Structural Basis for Bile Acid Binding and Activation of the Nuclear Receptor FXR

Mi, L.Z.Devarakonda, S.Harp, J.M.Han, Q.Pellicciari, R.Willson, T.M.Khorasanizadeh, S.Rastinejad, F.

(2003) Mol Cell 11: 1093-1100

  • DOI: https://doi.org/10.1016/s1097-2765(03)00112-6
  • Primary Citation of Related Structures:
    1OSV, 1OT7

  • PubMed Abstract:

    The nuclear receptor FXR is the sensor of physiological levels of enterohepatic bile acids, the end products of cholesterol catabolism. Here we report crystal structures of the FXR ligand binding domain in complex with coactivator peptide and two different bile acids. An unusual A/B ring juncture, a feature associated with bile acids and no other steroids, provides ligand discrimination and triggers a pi-cation switch that activates FXR. Helix 12, the activation function 2 of the receptor, adopts the agonist conformation and stabilizes coactivator peptide binding. FXR is able to interact simultaneously with two coactivator motifs, providing a mechanism for enhanced binding of coactivators through intermolecular contacts between their LXXLL sequences. These FXR complexes provide direct insights into the design of therapeutic bile acids for treatment of hyperlipidemia and cholestasis.


  • Organizational Affiliation

    Department of Pharmacology, University of Virginia Health System, Charlottesville 22908, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Bile Acid Receptor
A, B
229Rattus norvegicusMutation(s): 0
Gene Names: NR1H4
UniProt
Find proteins for Q62735 (Rattus norvegicus)
Explore Q62735
Go to UniProtKB:  Q62735
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ62735
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
dodecamer peptide fragment of RPGR-interacting protein 1
C, D, E
12N/AMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Binding Affinity Annotations
IDSourceBinding Affinity
CHC BindingDB:  1OT7 EC50: min: 10, max: 9.90e+4 (nM) from 21 assay(s)
IU5 BindingDB:  1OT7 EC50: min: 5.00e+4, max: 1.00e+5 (nM) from 2 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free: 0.279
  • R-Value Work: 0.233
  • R-Value Observed: 0.233
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 99.536α = 90
b = 107.129β = 90
c = 69.203γ = 90
Software Package:
Software NamePurpose
HKL-2000data collection
SCALEPACKdata scaling
MOLREPphasing
CNSrefinement
HKL-2000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2004-03-23
    Type: Initial release
  • Version 1.1: 2008-04-02
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2024-02-14
    Changes: Data collection, Database references, Derived calculations
  • Version 1.4: 2024-04-03
    Changes: Refinement description
