1W7B | pdb_00001w7b

Annexin A2: Does it induce membrane aggregation by a new multimeric state of the protein.

PDB DOI: https://doi.org/10.2210/pdb1W7B/pdb

Classification: CALCIUM-BINDING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli DH5[alpha]
Mutation(s): Yes

Deposited: 2004-09-01 Released: 2004-11-04
Deposition Author(s): Rosengarth, A., Luecke, H.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.52 Å
R-Value Free:
0.240 (Depositor), 0.236 (DCC)
R-Value Work:
0.216 (Depositor), 0.212 (DCC)
R-Value Observed:
0.216 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 1W7B

This is version 1.4 of the entry. See complete history.

Literature

Annexin A2: Does It Induce Membrane Aggregation by a New Multimeric State of the Protein

Rosengarth, A., Luecke, H.

(2004) Annexins 1: 129

Macromolecule Content

Total Structure Weight: 38.72 kDa
Atom Count: 2,913
Modeled Residue Count: 319
Deposited Residue Count: 339
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ANNEXIN A2	A	339	Homo sapiens	Mutation(s): 1
UniProt & NIH Common Fund Data Resources
Find proteins for P07355 (Homo sapiens) Explore P07355 Go to UniProtKB: P07355
PHAROS: P07355 GTEx: ENSG00000182718
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P07355
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.52 Å
R-Value Free: 0.240 (Depositor), 0.236 (DCC)
R-Value Work: 0.216 (Depositor), 0.212 (DCC)
R-Value Observed: 0.216 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.352	α = 90
b = 62.834	β = 90
c = 119.017	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
DENZO	data reduction
SCALEPACK	data scaling
CNS	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2004-11-04

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2004-11-04
Type: Initial release
Version 1.1: 2011-05-08
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Version format compliance
Version 1.3: 2018-01-31
Changes: Source and taxonomy
Version 1.4: 2024-05-08
Changes: Data collection, Database references, Other
