1W7G

Alpha-thrombin complex with sulfated hirudin (residues 54-65) and L- Arginine template inhibitor CS107


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.243
  • R-Value Observed: 0.243

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.4 of the entry. See complete history


Literature

Design, Synthesis and Evaluation of Graftable Thrombin Inhibitors for the Preparation of Blood-Compatible Polymer Materials.

Salvagnini, C.Michaux, C.Remiche, J.Wouters, J.Charlier, P.Marchand-Brynaert, J.

(2005) Org Biomol Chem 3: 4209

  • DOI: https://doi.org/10.1039/b510239a
  • Primary Citation of Related Structures:
    1W7G

  • PubMed Abstract:

    Piperazinyl-amide derivatives of N-alpha-(3-trifluoromethyl-benzenesulfonyl)-L-arginine (1) were synthesized as graftable thrombin inhibitors. The possible disturbance of biological activity due to a variable spacer-arm fixed on the N-4 piperazinyl position was evaluated in vitro, against human alpha-thrombin, and in blood coagulation assay. Molecular modelling (in silico analysis) and X-ray diffraction studies of thrombin-inhibitor complexes were also performed. The fixation of bioactive molecules on poly(butylene terephthalate) (PBT) and poly(ethylene terephthalate) (PET) membranes was performed by wet chemistry treatment and evaluated by XPS analysis. Surface grafting of inhibitor 1d improved the membrane hemocompatibility by reducing blood clot formation on the modified surface.


  • Organizational Affiliation

    Unité de Chimie Organique et Médicinale, Université catholique de Louvain, Bâtiment Lavoisier, place Louis Pasteur 1, B-1348, Louvain-la-Neuve, Belgium.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
THROMBINA [auth H]259Homo sapiensMutation(s): 0
EC: 3.4.21.5
UniProt & NIH Common Fund Data Resources
Find proteins for P00734 (Homo sapiens)
Explore P00734
Go to UniProtKB:  P00734
PHAROS:  P00734
GTEx:  ENSG00000180210
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00734
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
HIRUDIN IB [auth I]12Hirudo medicinalisMutation(s): 0
UniProt
Find proteins for P09945 (Hirudo medicinalis)
Explore P09945
Go to UniProtKB:  P09945
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP09945
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
THROMBINC [auth L]36Homo sapiensMutation(s): 0
EC: 3.4.21.5
UniProt & NIH Common Fund Data Resources
Find proteins for P00734 (Homo sapiens)
Explore P00734
Go to UniProtKB:  P00734
PHAROS:  P00734
GTEx:  ENSG00000180210
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00734
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MIU
Query on MIU

Download Ideal Coordinates CCD File
D [auth H]N-{(1S)-1-{[4-(3-AMINOPROPYL)PIPERAZIN-1-YL]CARBONYL}-4-[(DIAMINOMETHYLENE)AMINO]BUTYL}-3-(TRIFLUOROMETHYL)BENZENESULFONAMIDE
C20 H32 F3 N7 O3 S
KGJKWHCPJPBEJP-KRWDZBQOSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
MIU PDBBind:  1W7G Ki: 8000 (nM) from 1 assay(s)
BindingDB:  1W7G Ki: 1900 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.65 Å
  • R-Value Free: 0.272
  • R-Value Work: 0.243
  • R-Value Observed: 0.243
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 70.51α = 90
b = 71.343β = 100.59
c = 72.555γ = 90
Software Package:
Software NamePurpose
CNSrefinement
MOSFLMdata reduction
SCALAdata scaling
AMoREphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-05-24
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Atomic model, Database references, Derived calculations, Non-polymer description, Structure summary, Version format compliance
  • Version 1.2: 2019-01-30
    Changes: Data collection, Experimental preparation
  • Version 1.3: 2023-12-13
    Changes: Data collection, Database references, Derived calculations, Other, Refinement description
  • Version 1.4: 2024-11-13
    Changes: Structure summary
