3BV9

Structure of Thrombin Bound to the Inhibitor FM19


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.190
  • R-Value Observed: 0.190

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.4 of the entry. See complete history


Literature

Thrombostatin FM compounds: direct thrombin inhibitors - mechanism of action in vitro and in vivo.

Nieman, M.T.Burke, F.Warnock, M.Zhou, Y.Sweigart, J.Chen, A.Ricketts, D.Lucchesi, B.R.Chen, Z.Di Cera, E.Hilfinger, J.Kim, J.S.Mosberg, H.I.Schmaier, A.H.

(2008) J Thromb Haemost 6: 837-845

  • DOI: https://doi.org/10.1111/j.1538-7836.2008.02937.x
  • Primary Citation of Related Structures:
    3BV9

  • PubMed Abstract:

    Novel pentapeptides called Thrombostatin FM compounds consisting mostly of D-isomers and unusual amino acids were prepared based upon the stable angiotensin converting enzyme breakdown product of bradykinin - RPPGF. These peptides are direct thrombin inhibitors prolonging the thrombin clotting time, activated partial thromboplastin time, and prothrombin time at >or=0.78, 1.6, and 1.6 microm, respectively. They competitively inhibit alpha-thrombin-induced cleavage of a chromogenic substrate at 4.4-8.2 microm. They do not significantly inhibit plasma kallikrein, factor (F) XIIa, FXIa, FIXa, FVIIa-TF, FXa, plasmin or cathepsin G. One form, FM19 [rOicPaF(p-Me)], blocks alpha-thrombin-induced calcium flux in fibroblasts with an IC(50) of 6.9 +/- 1.2 microm. FM19 achieved 100% inhibition of threshold alpha- or gamma-thrombin-induced platelet aggregation at 8.4 +/- 4.7 microm and 16 +/- 4 microm, respectively. The crystal structure of thrombin in complex with FM19 shows that the N-terminal D-Arg retrobinds into the S1 pocket, its second residue Oic interacts with His-57, Tyr-60a and Trp-60d, and its C-terminal p-methyl Phe engages thrombin's aryl binding site composed of Ile-174, Trp-215, and Leu-99. When administered intraperitoneal, intraduodenal, or orally to mice, FM19 prolongs thrombin clotting times and delays carotid artery thrombosis. FM19, a low affinity reversible direct thrombin inhibitor, might be useful as an add-on agent to address an unmet need in platelet inhibition in acute coronary syndromes in diabetics and others who with all current antiplatelet therapy still have reactive platelets.


  • Organizational Affiliation

    Division of Hematology and Oncology, Department of Medicine, Case Western Reserve University, Cleveland, OH 44106-7284, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Thrombin light chain31Homo sapiensMutation(s): 0
Gene Names: F2
EC: 3.4.21.5
UniProt & NIH Common Fund Data Resources
Find proteins for P00734 (Homo sapiens)
Explore P00734
Go to UniProtKB:  P00734
PHAROS:  P00734
GTEx:  ENSG00000180210
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00734
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Thrombin heavy chain259Homo sapiensMutation(s): 1
Gene Names: F2
EC: 3.4.21.5
UniProt & NIH Common Fund Data Resources
Find proteins for P00734 (Homo sapiens)
Explore P00734
Go to UniProtKB:  P00734
PHAROS:  P00734
GTEx:  ENSG00000180210
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00734
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
FM19 inhibitor6N/AMutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
4PH
Query on 4PH
C
L-PEPTIDE LINKINGC10 H13 N O2PHE
Biologically Interesting Molecules (External Reference) 1 Unique
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free: 0.239
  • R-Value Work: 0.190
  • R-Value Observed: 0.190
  • Space Group: P 61 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 80.907α = 90
b = 80.907β = 90
c = 183.718γ = 120
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data collection
HKL-2000data reduction
SCALEPACKdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2008-03-04
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Atomic model, Database references, Derived calculations, Non-polymer description, Structure summary, Version format compliance
  • Version 1.2: 2012-12-12
    Changes: Other
  • Version 1.3: 2021-10-20
    Changes: Database references, Derived calculations
  • Version 1.4: 2023-08-30
    Changes: Data collection, Refinement description
