3KOK | pdb_00003kok

Crystal structure of cobalt (II) human carbonic anhydrase II at pH 8.5


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:
    0.227 (Depositor), 0.216 (DCC)
  • R-Value Work:
    0.219 (Depositor), 0.181 (DCC)
  • R-Value Observed:
    0.220 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 3KOK

This is version 1.2 of the entry. See complete history

Literature

Comparison of solution and crystal properties of Co(II)-substituted human carbonic anhydrase II.

Avvaru, B.S.Arenas, D.J.Tu, C.Tanner, D.B.McKenna, R.Silverman, D.N.

(2010) Arch Biochem Biophys 502: 53-59

  • DOI: https://doi.org/10.1016/j.abb.2010.07.010
  • Primary Citation Related Structures:
    3KOI, 3KOK, 3KON

  • PubMed Abstract:

    The visible absorption of crystals of Co(II)-substituted human carbonic anhydrase II (Co(II)-HCA II) were measured over a pH range of 6.0-11.0 giving an estimate of pK(a) 8.4 for the ionization of the metal-bound water in the crystal. This is higher by about 1.2 pK(a) units than the pK(a) near 7.2 for Co(II)-CA II in solution. This effect is attributed to a nonspecific ionic strength effect of 1.4M citrate in the precipitant solution used in the crystal growth. A pK(a) of 8.3 for the aqueous ligand of the cobalt was measured for Co(II)-HCA II in solution containing 0.8M citrate. Citrate is not an inhibitor of the catalytic activity of Co(II)-HCA II and was not observed in crystal structures. The X-ray structures at 1.5-1.6A resolution of Co(II)-HCA II were determined for crystals prepared at pH 6.0, 8.5 and 11.0 and revealed no conformational changes of amino-acid side chains as a result of the use of citrate. However, the studies of Co(II)-HCA II did reveal a change in metal coordination from tetrahedral at pH 11 to a coordination consistent with a mixed population of both tetrahedral and penta-coordinate at pH 8.5 to an octahedral geometry characteristic of the oxidized enzyme Co(III)-HCA II at pH 6.0.


  • Organizational Affiliation
    • Department of Biochemistry and Molecular Biology, University of Florida, Gainesville, FL 32610, USA.

Macromolecule Content

  • Total Structure Weight: 29.35 kDa
  • Atom Count: 2,292
  • Modeled Residue Count: 258
  • Deposited Residue Count: 260
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Carbonic anhydrase 2260Homo sapiensMutation(s): 0
EC: 4.2.1.1 (PDB Primary Data), 4.2.1.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P00918 (Homo sapiens)
Explore P00918
Go to UniProtKB:  P00918
PHAROS:  P00918
GTEx:  ENSG00000104267
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00918
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CO

Query on CO



Download:Ideal Coordinates CCD File
B [auth A]COBALT (II) ION
Co
XLJKHNWPARRRJB-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.50 Å
  • R-Value Free:  0.227 (Depositor), 0.216 (DCC)
  • R-Value Work:  0.219 (Depositor), 0.181 (DCC)
  • R-Value Observed: 0.220 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.366α = 90
b = 41.159β = 104.28
c = 72.062γ = 90
Software Package:
Software NamePurpose
CrystalCleardata collection
SHELXmodel building
SHELXL-97refinement
HKL-2000data reduction
HKL-2000data scaling
SHELXphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

  • Released Date: 2010-08-25
  • Deposition Author(s): Avvaru, B.S.

Revision History  (Full details and data files)

  • Version 1.0: 2010-08-25
    Type: Initial release
  • Version 1.1: 2011-07-13
    Changes: Version format compliance
  • Version 1.2: 2024-02-21
    Changes: Data collection, Database references, Derived calculations
