4E19 | pdb_00004e19

Crystal structure of RNase H1 from halophilic archaeon Halobacterium salinarum NRC-1

• PDB DOI: https://doi.org/10.2210/pdb4E19/pdb

• Classification: HYDROLASE
• Organism(s): Halobacterium salinarum NRC-1
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2012-03-06 Released: 2013-03-06
• Deposition Author(s): You, D.J., Angkawidjaja, C., Koga, Y., Kanaya, S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.41 Å
• R-Value Free:
  0.207 (Depositor), 0.210 (DCC)
• R-Value Work:
  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed:
  0.173 (Depositor)

Starting Model: experimental

Literature

Crystal structure of RNase H1 from halophilic archaeon Halobacterium salinarum NRC-1

You, D.J., Angkawidjaja, C., Koga, Y., Kanaya, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 42.28 kDa
• Atom Count: 2,302
• Modeled Residue Count: 265
• Deposited Residue Count: 398
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ribonuclease H1	A, B	199	Halobacterium salinarum NRC-1	Mutation(s): 0  Gene Names: VNG_0255C EC: 3.1.26.4
UniProt
Find proteins for Q9HSF6 (Halobacterium salinarum (strain ATCC 700922 / JCM 11081 / NRC-1)) Explore Q9HSF6  Go to UniProtKB:  Q9HSF6

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MN	C [auth A], D [auth A], E [auth B], F [auth B], G [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.41 Å
• R-Value Free:  0.207 (Depositor), 0.210 (DCC)
• R-Value Work:  0.172 (Depositor), 0.180 (DCC)
• R-Value Observed: 0.173 (Depositor)

Space Group: I 4₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 115.802	α = 90
b = 115.802	β = 90
c = 38.282	γ = 90

Software Package:

Software Name	Purpose
DENZO	data reduction
SCALEPACK	data scaling
MOLREP	phasing
DM	phasing
REFMAC	refinement
PDB_EXTRACT	data extraction
HKL-2000	data collection
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-03-06
Deposition Author(s): You, D.J., Angkawidjaja, C., Koga, Y., Kanaya, S.

Revision History

• Version 1.0: 2013-03-06
  Type: Initial release

• Version 1.1: 2017-11-15
  Changes: Refinement description
• Version 1.2: 2023-11-08
  Changes: Data collection, Database references, Derived calculations, Refinement description
