4EZ5

CDK6 (monomeric) in complex with inhibitor

• PDB DOI: https://doi.org/10.2210/pdb4EZ5/pdb

• Classification: TRANSFERASE/TRANSFERASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2012-05-02 Released: 2013-02-06
• Deposition Author(s): Chopra, R., Xu, M.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.70 Å
• R-Value Free:
  0.287 (Depositor), 0.280 (DCC)
• R-Value Work:
  0.216 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.220 (Depositor)

Starting Model: experimental

Literature

Fragment-Based Discovery of 7-Azabenzimidazoles as Potent, Highly Selective, and Orally Active CDK4/6 Inhibitors.

Cho, Y.S., Angove, H., Brain, C., Chen, C.H., Cheng, H., Cheng, R., Chopra, R., Chung, K., Congreve, M., Dagostin, C., Davis, D.J., Feltell, R., Giraldes, J., Hiscock, S.D., Kim, S., Kovats, S., Lagu, B., Lewry, K., Loo, A., Lu, Y., Luzzio, M., Maniara, W., McMenamin, R., Mortenson, P.N., Benning, R., O'Reilly, M., Rees, D.C., Shen, J., Smith, T., Wang, Y., Williams, G., Woolford, A.J., Wrona, W., Xu, M., Yang, F., Howard, S.

(2012) ACS Med Chem Lett 3: 445-449

• PubMed: 24900493
• DOI: https://doi.org/10.1021/ml200241a
• Primary Citation of Related Structures:
  4AUA, 4EZ5


• PubMed Abstract:


  Herein, we describe the discovery of potent and highly selective inhibitors of both CDK4 and CDK6 via structure-guided optimization of a fragment-based screening hit. CDK6 X-ray crystallography and pharmacokinetic data steered efforts in identifying compound 6, which showed >1000-fold selectivity for CDK4 over CDKs 1 and 2 in an enzymatic assay. Furthermore, 6 demonstrated in vivo inhibition of pRb-phosphorylation and oral efficacy in a Jeko-1 mouse xenograft model.

---

Organizational Affiliation:

Novartis Institutes for Biomedical Research , 250 Massachusetts Avenue, Cambridge, Massachusetts 02139, United States.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 35.5 kDa
• Atom Count: 2,098
• Modelled Residue Count: 258
• Deposited Residue Count: 307
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cyclin-dependent kinase 6	A	307	Homo sapiens	Mutation(s): 0  Gene Names: CDK6, CDKN6 EC: 2.7.11.22
UniProt & NIH Common Fund Data Resources
Find proteins for Q00534 (Homo sapiens) Explore Q00534  Go to UniProtKB:  Q00534
PHAROS:  Q00534 GTEx:  ENSG00000105810

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
0RS	B [auth A]	{5-[4-(dimethylamino)piperidin-1-yl]-1H-imidazo[4,5-b]pyridin-2-yl}[2-(isoquinolin-4-yl)pyridin-4-yl]methanone C28 H27 N7 O VSHURSPEQITHNX-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
0RS	BindingDB:  4EZ5	IC50: 300 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.70 Å
• R-Value Free:  0.287 (Depositor), 0.280 (DCC)
• R-Value Work:  0.216 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.220 (Depositor)

Space Group: I 4

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 102.478	α = 90
b = 102.478	β = 90
c = 59.987	γ = 90

Software Package:

Software Name	Purpose
d*TREK	data scaling
d*TREK	data reduction
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History

Deposition Data

• Released Date: 2013-02-06
Deposition Author(s): Chopra, R., Xu, M.

Revision History

• Version 1.0: 2013-02-06
  Type: Initial release

• Version 1.1: 2014-09-24
  Changes: Database references
• Version 1.2: 2018-01-24
  Changes: Experimental preparation
• Version 1.3: 2023-09-13
  Changes: Data collection, Database references, Derived calculations, Refinement description
