4KKG | pdb_00004kkg

Crystal structure of apo and AMP-bound JNK3

PDB DOI: https://doi.org/10.2210/pdb4KKG/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2013-05-06 Released: 2014-05-21
Deposition Author(s): Han, B.G., Shim, M.B., Ahn, H.C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.300 (Depositor), 0.310 (DCC)
R-Value Work:
0.239 (Depositor), 0.240 (DCC)
R-Value Observed:
0.242 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

crystal structure of apo and AMP-bound JNK3

Han, B.G., Shim, M.B., Ahn, H.C.

To be published.

Macromolecule Content

Total Structure Weight: 42.12 kDa
Atom Count: 2,897
Modeled Residue Count: 353
Deposited Residue Count: 365
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 10	A	365	Homo sapiens	Mutation(s): 0 Gene Names: MAPK10, JNK3, JNK3A, PRKM10, SAPK1B EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for P53779 (Homo sapiens) Explore P53779 Go to UniProtKB: P53779
PHAROS: P53779 GTEx: ENSG00000109339
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P53779
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.300 (Depositor), 0.310 (DCC)
R-Value Work: 0.239 (Depositor), 0.240 (DCC)
R-Value Observed: 0.242 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 50.59	α = 90
b = 71.732	β = 90
c = 107.569	γ = 90

Software Package:

Software Name	Purpose
PHASES	phasing
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling

Structure Validation

View Full Validation Report

Entry History

Deposition Data

Released Date: 2014-05-21

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2014-05-21
Type: Initial release
Version 1.1: 2024-02-28
Changes: Data collection, Database references
