5C27

Crystal structure of SYK in complex with compound 2


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.177
  • R-Value Observed: 0.179

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Imidazotriazines: Spleen Tyrosine Kinase (Syk) Inhibitors Identified by Free-Energy Perturbation (FEP).

Lovering, F.Aevazelis, C.Chang, J.Dehnhardt, C.Fitz, L.Han, S.Janz, K.Lee, J.Kaila, N.McDonald, J.Moore, W.Moretto, A.Papaioannou, N.Richard, D.Ryan, M.S.Wan, Z.K.Thorarensen, A.

(2016) ChemMedChem 11: 217-233

  • DOI: https://doi.org/10.1002/cmdc.201500333
  • Primary Citation of Related Structures:
    5C26, 5C27

  • PubMed Abstract:

    There has been significant interest in spleen tyrosine kinase (Syk) owing to its role in a number of disease states, including autoimmunity, inflammation, and cancer. Ongoing therapeutic programs have resulted in several compounds that are now in clinical use. Herein we report our optimization of the imidazopyrazine core scaffold of Syk inhibitors through the use of empirical and computational approaches. Free-energy perturbation (FEP) methods with MCPRO+ were undertaken to calculate the relative binding free energies for several alternate scaffolds. FEP was first applied retrospectively to determine if there is any predictive value; this resulted in 12 of 13 transformations being predicted in a directionally correct manner. FEP was then applied in a prospective manner to evaluate 17 potential targets, resulting in the realization of imidazotriazine 17 (3-(4-(3,4-dimethoxyphenylamino)imidazo[1,2-f][1,2,4]triazin-2-yl)benzamide), which shows a tenfold improvement in activity relative to the parent compound and no increase in atom count. Optimization of 17 led to compounds with nanomolar cellular activity.


  • Organizational Affiliation

    Worldwide Medicinal Chemistry, Pfizer Worldwide R&D, 610 Main Street, Cambridge, MA, 02139, USA. frank.lovering@pfizer.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tyrosine-protein kinase SYK299Homo sapiensMutation(s): 0
Gene Names: SYK
EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for P43405 (Homo sapiens)
Explore P43405
Go to UniProtKB:  P43405
PHAROS:  P43405
GTEx:  ENSG00000165025
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP43405
Sequence Annotations
Expand
  • Reference Sequence

Find similar proteins by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
GLU-VAL-TYR-GLU-SERB [auth D]5Homo sapiensMutation(s): 0
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
50J
Query on 50J

Download Ideal Coordinates CCD File
C [auth A]3-{8-[(3,4-dimethoxyphenyl)amino]imidazo[1,2-a]pyrazin-6-yl}-N-[4-(methylcarbamoyl)phenyl]benzamide
C29 H26 N6 O4
OZJUQJCHSOXJDE-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
D [auth A]GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
PTR
Query on PTR
A
L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.15 Å
  • R-Value Free: 0.225
  • R-Value Work: 0.177
  • R-Value Observed: 0.179
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 39.879α = 90
b = 84.875β = 90
c = 89.592γ = 90
Software Package:
Software NamePurpose
BUSTERrefinement
Aimlessdata scaling
SCALAdata scaling
BUSTERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2015-10-07
    Type: Initial release
  • Version 1.1: 2016-02-03
    Changes: Database references
  • Version 1.2: 2024-11-13
    Changes: Data collection, Database references, Derived calculations, Structure summary
