Fragment-Based Drug Discovery Targeting Inhibitor of Apoptosis Proteins: Compound 21

Experimental Data Snapshot

  • Resolution: 2.33 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.209
  • R-Value Observed: 0.213

wwPDB Validation   3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history


Fragment-Based Drug Discovery Targeting Inhibitor of Apoptosis Proteins: Discovery of a Non-Alanine Lead Series with Dual Activity Against cIAP1 and XIAP.

Chessari, G.Buck, I.M.Day, J.E.Day, P.J.Iqbal, A.Johnson, C.N.Lewis, E.J.Martins, V.Miller, D.Reader, M.Rees, D.C.Rich, S.J.Tamanini, E.Vitorino, M.Ward, G.A.Williams, P.A.Williams, G.Wilsher, N.E.Woolford, A.J.

(2015) J Med Chem 58: 6574-6588

  • DOI: https://doi.org/10.1021/acs.jmedchem.5b00706
  • Primary Citation of Related Structures:
    5C0K, 5C0L, 5C3H, 5C3K, 5C7A, 5C7B, 5C7C, 5C7D, 5C83, 5C84

  • PubMed Abstract:

    Inhibitor of apoptosis proteins (IAPs) are important regulators of apoptosis and pro-survival signaling pathways whose deregulation is often associated with tumor genesis and tumor growth. IAPs have been proposed as targets for anticancer therapy, and a number of peptidomimetic IAP antagonists have entered clinical trials. Using our fragment-based screening approach, we identified nonpeptidic fragments binding with millimolar affinities to both cellular inhibitor of apoptosis protein 1 (cIAP1) and X-linked inhibitor of apoptosis protein (XIAP). Structure-based hit optimization together with an analysis of protein-ligand electrostatic potential complementarity allowed us to significantly increase binding affinity of the starting hits. Subsequent optimization gave a potent nonalanine IAP antagonist structurally distinct from all IAP antagonists previously reported. The lead compound had activity in cell-based assays and in a mouse xenograft efficacy model and represents a highly promising start point for further optimization.

  • Organizational Affiliation

    Astex Pharmaceuticals , 436 Cambridge Science Park, Milton Road, Cambridge, CB4 0QA, United Kingdom.

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
E3 ubiquitin-protein ligase XIAP110Homo sapiensMutation(s): 0
EC: 6.3.2
UniProt & NIH Common Fund Data Resources
Find proteins for P98170 (Homo sapiens)
Explore P98170
Go to UniProtKB:  P98170
PHAROS:  P98170
GTEx:  ENSG00000101966
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP98170
Sequence Annotations
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
Query on 4YN

Download Ideal Coordinates CCD File
C [auth A](2R,5R)-4-[2-(6-benzyl-3,3-dimethyl-2,3-dihydro-1H-pyrrolo[3,2-c]pyridin-1-yl)-2-oxoethyl]-5-(methoxymethyl)-2-methylpiperazin-1-ium
C25 H35 N4 O2
Query on ZN

Download Ideal Coordinates CCD File
B [auth A]ZINC ION
Binding Affinity Annotations
IDSourceBinding Affinity
4YN Binding MOAD:  5C83 IC50: 160 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Resolution: 2.33 Å
  • R-Value Free: 0.273
  • R-Value Work: 0.209
  • R-Value Observed: 0.213
  • Space Group: P 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.145α = 90
b = 71.145β = 90
c = 106.403γ = 90
Software Package:
Software NamePurpose
d*TREKdata reduction
d*TREKdata scaling

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Revision History  (Full details and data files)

  • Version 1.0: 2015-08-12
    Type: Initial release
  • Version 1.1: 2015-09-09
    Changes: Database references
  • Version 1.2: 2024-01-10
    Changes: Data collection, Database references, Refinement description
