5ETT

S. aureus 6-hydroxymethyl-7,8-dihydropterin pyrophosphokinase complexed with AMPCPP and inhibitor at 1.55 angstrom resolution


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.158
  • R-Value Observed: 0.160

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Structural Basis for the Selective Binding of Inhibitors to 6-Hydroxymethyl-7,8-dihydropterin Pyrophosphokinase from Staphylococcus aureus and Escherichia coli.

Dennis, M.L.Pitcher, N.P.Lee, M.D.DeBono, A.J.Wang, Z.C.Harjani, J.R.Rahmani, R.Cleary, B.Peat, T.S.Baell, J.B.Swarbrick, J.D.

(2016) J Med Chem 59: 5248-5263

  • DOI: https://doi.org/10.1021/acs.jmedchem.6b00002
  • Primary Citation of Related Structures:
    5ETK, 5ETL, 5ETM, 5ETN, 5ETO, 5ETP, 5ETQ, 5ETR, 5ETS, 5ETT, 5ETV

  • PubMed Abstract:

    6-Hydroxymethyl-7,8-dihydropterin pyrophosphokinase (HPPK) is a member of the folate biosynthesis pathway found in prokaryotes and lower eukaryotes that catalyzes the pyrophosphoryl transfer from the ATP cofactor to a 6-hydroxymethyl-7,8-dihydropterin substrate. We report the chemical synthesis of a series of S-functionalized 8-mercaptoguanine (8MG) analogues as substrate site inhibitors of HPPK and quantify binding against the E. coli and S. aureus enzymes (EcHPPK and SaHPPK). The results demonstrate that analogues incorporating acetophenone-based substituents have comparable affinities for both enzymes. Preferential binding of benzyl-substituted 8MG derivatives to SaHPPK was reconciled when a cryptic pocket unique to SaHPPK was revealed by X-ray crystallography. Differential chemical shift perturbation analysis confirmed this to be a common mode of binding for this series to SaHPPK. One compound (41) displayed binding affinities of 120 nM and 1.76 μM for SaHPPK and EcHPPK, respectively, and represents a lead for the development of more potent and selective inhibitors of SaHPPK.


  • Organizational Affiliation

    Monash Institute of Pharmaceutical Sciences, Monash University , Parkville, Victoria 3052, Australia.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
2-amino-4-hydroxy-6-hydroxymethyldihydropteridine pyrophosphokinaseA [auth B],
B [auth A]
161Staphylococcus aureusMutation(s): 0
Gene Names:
EC: 2.7.6.3
UniProt
Find proteins for Q2G0Q5 (Staphylococcus aureus (strain NCTC 8325 / PS 47))
Explore Q2G0Q5
Go to UniProtKB:  Q2G0Q5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2G0Q5
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
APC
Query on APC

Download Ideal Coordinates CCD File
C [auth B],
I [auth A]
DIPHOSPHOMETHYLPHOSPHONIC ACID ADENOSYL ESTER
C11 H18 N5 O12 P3
CAWZRIXWFRFUQB-IOSLPCCCSA-N
5RY
Query on 5RY

Download Ideal Coordinates CCD File
D [auth B],
J [auth A]
4-[(2-azanyl-6-oxidanylidene-1,9-dihydropurin-8-yl)sulfanylmethyl]-3-fluoranyl-benzenecarbonitrile
C13 H9 F N6 O S
GEUVDHJEINQZML-UHFFFAOYSA-N
MG
Query on MG

Download Ideal Coordinates CCD File
F [auth B],
G [auth B],
L [auth A],
M [auth A]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
NA
Query on NA

Download Ideal Coordinates CCD File
E [auth B],
H [auth B],
K [auth A]
SODIUM ION
Na
FKNQFGJONOIPTF-UHFFFAOYSA-N
Binding Affinity Annotations
IDSourceBinding Affinity
5RY BindingDB:  5ETT Kd: 590 (nM) from 1 assay(s)
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.55 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.158
  • R-Value Observed: 0.160
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 47.546α = 90
b = 68.404β = 105.94
c = 53.125γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
XDSdata reduction
Cootmodel building
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-05-04
    Type: Initial release
  • Version 1.1: 2016-06-22
    Changes: Database references
  • Version 1.2: 2023-09-27
    Changes: Data collection, Database references, Derived calculations, Refinement description
