5GSN

Tmm in complex with methimazole


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.203
  • R-Value Observed: 0.207

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Structural mechanism for bacterial oxidation of oceanic trimethylamine into trimethylamine N-oxide

Li, C.Y.Chen, X.L.Zhang, D.Wang, P.Sheng, Q.Peng, M.Xie, B.B.Qin, Q.L.Li, P.Y.Zhang, X.Y.Su, H.N.Song, X.Y.Shi, M.Zhou, B.C.Xun, L.Y.Chen, Y.Zhang, Y.Z.

(2017) Mol Microbiol 103: 992-1003

  • DOI: https://doi.org/10.1111/mmi.13605
  • Primary Citation of Related Structures:
    5GSN, 5IPY, 5IQ1, 5IQ4

  • PubMed Abstract:

    Trimethylamine (TMA) and trimethylamine N-oxide (TMAO) are widespread in the ocean and are important nitrogen source for bacteria. TMA monooxygenase (Tmm), a bacterial flavin-containing monooxygenase (FMO), is found widespread in marine bacteria and is responsible for converting TMA to TMAO. However, the molecular mechanism of TMA oxygenation by Tmm has not been explained. Here, we determined the crystal structures of two reaction intermediates of a marine bacterial Tmm (RnTmm) and elucidated the catalytic mechanism of TMA oxidation by RnTmm. The catalytic process of Tmm consists of a reductive half-reaction and an oxidative half-reaction. In the reductive half-reaction, FAD is reduced and a C4a-hydroperoxyflavin intermediate forms. In the oxidative half-reaction, this intermediate attracts TMA through electronic interactions. After TMA binding, NADP + bends and interacts with D317, shutting off the entrance to create a protected micro-environment for catalysis and exposing C4a-hydroperoxyflavin to TMA for oxidation. Sequence analysis suggests that the proposed catalytic mechanism is common for bacterial Tmms. These findings reveal the catalytic process of TMA oxidation by marine bacterial Tmm and first show that NADP + undergoes a conformational change in the oxidative half-reaction of FMOs.


  • Organizational Affiliation

    State Key Laboratory of Microbial Technology, Marine Biotechnology Research Center, Institute of Marine Science and Technology, Shandong University, Jinan, 250100, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Flavin-containing monooxygenase
A, B, C, D
453Roseovarius nubinhibens ISMMutation(s): 3
Gene Names: ISM_08155
EC: 1.14.13.148
UniProt
Find proteins for A3SLM3 (Roseovarius nubinhibens (strain ATCC BAA-591 / DSM 15170 / ISM))
Explore A3SLM3
Go to UniProtKB:  A3SLM3
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA3SLM3
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
FAD
Query on FAD

Download Ideal Coordinates CCD File
F [auth A],
I [auth B],
K [auth C],
N [auth D]
FLAVIN-ADENINE DINUCLEOTIDE
C27 H33 N9 O15 P2
VWWQXMAJTJZDQX-UYBVJOGSSA-N
NAP
Query on NAP

Download Ideal Coordinates CCD File
E [auth A],
H [auth B],
J [auth C],
M [auth D]
NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE
C21 H28 N7 O17 P3
XJLXINKUBYWONI-NNYOXOHSSA-N
MMZ
Query on MMZ

Download Ideal Coordinates CCD File
G [auth A],
L [auth C]
1-METHYL-1,3-DIHYDRO-2H-IMIDAZOLE-2-THIONE
C4 H6 N2 S
PMRYVIKBURPHAH-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.274
  • R-Value Work: 0.203
  • R-Value Observed: 0.207
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 60.849α = 90
b = 207.578β = 90.31
c = 72.517γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data scaling
HKL-3000data processing
PHENIXphasing
HKL-3000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Foundation of ChinaChina31290230

Revision History  (Full details and data files)

  • Version 1.0: 2017-01-18
    Type: Initial release
  • Version 1.1: 2017-03-22
    Changes: Database references
  • Version 1.2: 2017-09-27
    Changes: Data collection
  • Version 1.3: 2023-11-08
    Changes: Data collection, Database references, Refinement description
