5HPE | pdb_00005hpe

Phosphatase domain of PP5 bound to a phosphomimetic Cdc37 substrate peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.27 Å
  • R-Value Free:
    0.236 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.168 (Depositor), 0.171 (DCC)
  • R-Value Observed:
    0.175 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5HPE

This is version 1.3 of the entry. See complete history

Literature

Structural and functional basis of protein phosphatase 5 substrate specificity.

Oberoi, J.Dunn, D.M.Woodford, M.R.Mariotti, L.Schulman, J.Bourboulia, D.Mollapour, M.Vaughan, C.K.

(2016) Proc Natl Acad Sci U S A 113: 9009-9014

  • DOI: https://doi.org/10.1073/pnas.1603059113
  • Primary Citation Related Structures:
    5HPE

  • PubMed Abstract:

    The serine/threonine phosphatase protein phosphatase 5 (PP5) regulates hormone- and stress-induced cellular signaling by association with the molecular chaperone heat shock protein 90 (Hsp90). PP5-mediated dephosphorylation of the cochaperone Cdc37 is essential for activation of Hsp90-dependent kinases. However, the details of this mechanism remain unknown. We determined the crystal structure of a Cdc37 phosphomimetic peptide bound to the catalytic domain of PP5. The structure reveals PP5 utilization of conserved elements of phosphoprotein phosphatase (PPP) structure to bind substrate and provides a template for many PPP-substrate interactions. Our data show that, despite a highly conserved structure, elements of substrate specificity are determined within the phosphatase catalytic domain itself. Structure-based mutations in vivo reveal that PP5-mediated dephosphorylation is required for kinase and steroid hormone receptor release from the chaperone complex. Finally, our data show that hyper- or hypoactivity of PP5 mutants increases Hsp90 binding to its inhibitor, suggesting a mechanism to enhance the efficacy of Hsp90 inhibitors by regulation of PP5 activity in tumors.


  • Organizational Affiliation
    • Institute of Structural and Molecular Biology, Biological Sciences, University College London and Birkbeck College, London WC1E 7HX, United Kingdom;

Macromolecule Content

  • Total Structure Weight: 40.2 kDa
  • Atom Count: 2,747
  • Modeled Residue Count: 326
  • Deposited Residue Count: 350
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Serine/threonine-protein phosphatase 5,Hsp90 co-chaperone Cdc37350Homo sapiensMutation(s): 1
Gene Names: PPP5CPPP5CDC37
EC: 3.1.3.16
UniProt & NIH Common Fund Data Resources
Find proteins for P53041 (Homo sapiens)
Explore P53041
Go to UniProtKB:  P53041
PHAROS:  P53041
GTEx:  ENSG00000011485
Find proteins for Q16543 (Homo sapiens)
Explore Q16543
Go to UniProtKB:  Q16543
PHAROS:  Q16543
GTEx:  ENSG00000105401
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP53041Q16543
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.27 Å
  • R-Value Free:  0.236 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.168 (Depositor), 0.171 (DCC)
  • R-Value Observed: 0.175 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 42.314α = 90
b = 65.164β = 90
c = 132.117γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
United Kingdom--

Revision History  (Full details and data files)

  • Version 1.0: 2016-07-27
    Type: Initial release
  • Version 1.1: 2016-08-10
    Changes: Database references
  • Version 1.2: 2016-08-24
    Changes: Database references
  • Version 1.3: 2024-01-10
    Changes: Data collection, Database references, Refinement description
