5L3J | pdb_00005l3j

ESCHERICHIA COLI DNA GYRASE B IN COMPLEX WITH BENZOTHIAZOLE-BASED INHIBITOR


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.83 Å
  • R-Value Free:
    0.288 (Depositor), 0.282 (DCC)
  • R-Value Work:
    0.258 (Depositor), 0.250 (DCC)
  • R-Value Observed:
    0.260 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 5L3J

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Discovery of Benzothiazole Scaffold-Based DNA Gyrase B Inhibitors.

Gjorgjieva, M.Tomasic, T.Barancokova, M.Katsamakas, S.Ilas, J.Tammela, P.Peterlin Masic, L.Kikelj, D.

(2016) J Med Chem 59: 8941-8954

  • DOI: https://doi.org/10.1021/acs.jmedchem.6b00864
  • Primary Citation Related Structures:
    5L3J

  • PubMed Abstract:

    Bacterial DNA gyrase and topoisomerase IV control the topological state of DNA during replication and are validated targets for antibacterial drug discovery. Starting from our recently reported 4,5,6,7-tetrahydrobenzo[1,2-d]thiazole-based DNA gyrase B inhibitors, we replaced their central core with benzothiazole-2,6-diamine scaffold and interchanged substituents in positions 2 and 6. This resulted in equipotent nanomolar inhibitors of DNA gyrase from Escherichia coli displaying improved inhibition of Staphylococcus aureus DNA gyrase and topoisomerase IV from both bacteria. Compound 27 was the most balanced inhibitor of DNA gyrase and topoisomerase IV from both E. coli and S. aureus. The crystal structure of the 2-((2-(4,5-dibromo-1H-pyrrole-2-carboxamido)benzothiazol-6-yl)amino)-2-oxoacetic acid (24) in complex with E. coli DNA gyrase B revealed the binding mode of the inhibitor in the ATP-binding pocket. Only some compounds possessed weak antibacterial activity against Gram-positive bacteria. These results provide a basis for structure-based optimization toward dual DNA gyrase and topoisomerase IV inhibitors with antibacterial activity.


  • Organizational Affiliation
    • Faculty of Pharmacy, University of Ljubljana , Aškerčeva 7, 1000 Ljubljana, Slovenia.

Macromolecule Content

  • Total Structure Weight: 42.36 kDa
  • Atom Count: 2,844
  • Modeled Residue Count: 360
  • Deposited Residue Count: 378
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA gyrase subunit B378Escherichia coliMutation(s): 0
Gene Names: gyrBZ5190ECs4634
EC: 5.99.1.3 (PDB Primary Data), 5.6.2.2 (UniProt)
UniProt
Find proteins for P0AES6 (Escherichia coli (strain K12))
Explore P0AES6
Go to UniProtKB:  P0AES6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0AES6
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
6G9

Query on 6G9



Download:Ideal Coordinates CCD File
B [auth A]2-[[2-[[4,5-bis(bromanyl)-1~{H}-pyrrol-2-yl]carbonylamino]-1,3-benzothiazol-6-yl]amino]-2-oxidanylidene-ethanoic acid
C14 H8 Br2 N4 O4 S
ZDVZBRWEKLWNNU-UHFFFAOYSA-N
IOD

Query on IOD



Download:Ideal Coordinates CCD File
C [auth A]IODIDE ION
I
XMBWDFGMSWQBCA-UHFFFAOYSA-M
Binding Affinity Annotations
IDSourceBinding Affinity
6G9 BindingDB:  5L3J Kd: 230 (nM) from 1 assay(s)
IC50: 58 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.83 Å
  • R-Value Free:  0.288 (Depositor), 0.282 (DCC)
  • R-Value Work:  0.258 (Depositor), 0.250 (DCC)
  • R-Value Observed: 0.260 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 116.286α = 90
b = 49.585β = 93.48
c = 70.212γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2016-08-31
    Type: Initial release
  • Version 1.1: 2016-10-26
    Changes: Database references
  • Version 1.2: 2024-05-08
    Changes: Data collection, Database references
