5UVU

BRD4_BD2_A-1461028

• PDB DOI: https://doi.org/10.2210/pdb5UVU/pdb

• Classification: SIGNALING PROTEIN/INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Enterobacteria phage L1
• Mutation(s): No


• Deposited: 2017-02-20 Released: 2017-06-21
• Deposition Author(s): Park, C.H.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.66 Å
• R-Value Free: 0.212
• R-Value Work: 0.189
• R-Value Observed: 0.190

Literature

Complex structure of BRD4_BD2_A-1461028

Park, C.H.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 13.2 kDa
• Atom Count: 1,104
• Modelled Residue Count: 107
• Deposited Residue Count: 109
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 4	A	109	Homo sapiens	Mutation(s): 0  Gene Names: BRD4, HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens) Explore O60885  Go to UniProtKB:  O60885
PHAROS:  O60885 GTEx:  ENSG00000141867

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
8O4	B [auth A]	7-(cyclopropylmethyl)-2-methyl-10-[(methylsulfonyl)methyl]-2,4,6,7-tetrahydro-3H-2,4,7-triazadibenzo[cd,f]azulen-3-one C21 H23 N3 O3 S AGRVPCMMHQFJTH-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
8O4	BindingDB:  5UVU	Ki: 8.4 (nM) from 1 assay(s)
		IC50: 4.6 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.66 Å
• R-Value Free: 0.212
• R-Value Work: 0.189
• R-Value Observed: 0.190
• Space Group: P 2₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.712	α = 90
b = 70.541	β = 90
c = 33.648	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
SCALA	data scaling
Coot	model building
BUSTER	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2017-06-21
Deposition Author(s): Park, C.H.

Revision History

• Version 1.0: 2017-06-21
  Type: Initial release

• Version 1.1: 2024-03-06
  Changes: Data collection, Database references
