5VKC | pdb_00005vkc

Crystal structure of MCL-1 in complex with a BIM competitive inhibitor

PDB DOI: https://doi.org/10.2210/pdb5VKC/pdb

Classification: signaling protein/inhibitor
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2017-04-21 Released: 2017-05-03
Deposition Author(s): Judge, R.A., Souers, A.J.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.31 Å
R-Value Free:
0.222 (Depositor), 0.229 (DCC)
R-Value Work:
0.201 (Depositor), 0.203 (DCC)
R-Value Observed:
0.202 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Structure-guided design of a series of MCL-1 inhibitors with high affinity and selectivity.

Bruncko, M., Wang, L., Sheppard, G.S., Phillips, D.C., Tahir, S.K., Xue, J., Erickson, S., Fidanze, S., Fry, E., Hasvold, L., Jenkins, G.J., Jin, S., Judge, R.A., Kovar, P.J., Madar, D., Nimmer, P., Park, C., Petros, A.M., Rosenberg, S.H., Smith, M.L., Song, X., Sun, C., Tao, Z.F., Wang, X., Xiao, Y., Zhang, H., Tse, C., Leverson, J.D., Elmore, S.W., Souers, A.J.

(2015) J Med Chem 58: 2180-2194

PubMed: 25679114 Search on PubMed
DOI: https://doi.org/10.1021/jm501258m
Primary Citation Related Structures:
5VKC, 6B4L, 6B4U

PubMed Abstract:
Myeloid cell leukemia 1 (MCL-1) is a BCL-2 family protein that has been implicated in the progression and survival of multiple tumor types. Herein we report a series of MCL-1 inhibitors that emanated from a high throughput screening (HTS) hit and progressed via iterative cycles of structure-guided design. Advanced compounds from this series exhibited subnanomolar affinity for MCL-1 and excellent selectivity over other BCL-2 family proteins as well as multiple kinases and GPCRs. In a MCL-1 dependent human tumor cell line, administration of compound 30b rapidly induced caspase activation with associated loss in cell viability. The small molecules described herein thus comprise effective tools for studying MCL-1 biology.

Organizational Affiliation

AbbVie Inc. , 1 North Waukegan Road, North Chicago, Illinois 60064, United States.

Macromolecule Content

Total Structure Weight: 37.94 kDa
Atom Count: 2,572
Modeled Residue Count: 288
Deposited Residue Count: 314
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Induced myeloid leukemia cell differentiation protein Mcl-1	A, B	157	Homo sapiens	Mutation(s): 0 Gene Names: MCL1, BCL2L3
UniProt & NIH Common Fund Data Resources
Find proteins for Q07820 (Homo sapiens) Explore Q07820 Go to UniProtKB: Q07820
PHAROS: Q07820 GTEx: ENSG00000143384
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q07820
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
9EA Query on 9EA Download:Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain C [auth A] MOL2 format, chain K [auth B] MOL2 format, chain C [auth A] mmCIF format, chain K [auth B] mmCIF format, chain C [auth A]	C [auth A], K [auth B]	7-(3-{[4-(4-acetylpiperazin-1-yl)phenoxy]methyl}-1,5-dimethyl-1H-pyrazol-4-yl)-3-{3-[(naphthalen-1-yl)oxy]propyl}-1-[(pyridin-3-yl)methyl]-1H-indole-2-carboxylic acid C₄₆ H₄₆ N₆ O₅ VKKQBUSCPZGZBT-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain K [auth B]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain N [auth B] SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain N [auth B] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain N [auth B] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A] E [auth A] F [auth A] G [auth A] H [auth A] D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], L [auth B], M [auth B], N [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth B]

Binding Affinity Annotations
ID	Source	Binding Affinity
9EA	BindingDB: 5VKC	Ki: min: 1.8, max: 98 (nM) from 2 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.31 Å
R-Value Free: 0.222 (Depositor), 0.229 (DCC)
R-Value Work: 0.201 (Depositor), 0.203 (DCC)
R-Value Observed: 0.202 (Depositor)

Space Group: P 3₂

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.92	α = 90
b = 63.92	β = 90
c = 91.4	γ = 120

Software Package:

Software Name	Purpose
SCALEPACK	data scaling
BUSTER	refinement
PDB_EXTRACT	data extraction
DENZO	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

Deposition Data

Released Date: 2017-05-03

Deposition Author(s):

Judge, R.A.

Souers, A.J.

Revision History (Full details and data files)

Version 1.0: 2017-05-03
Type: Initial release
Version 1.1: 2017-08-23
Changes: Data collection
Version 1.2: 2024-03-13
Changes: Data collection, Database references, Derived calculations
