5VPB | pdb_00005vpb

Transcription factor FosB/JunD bZIP domain in its oxidized form, type-I crystal

  • Classification: TRANSCRIPTION
  • Organism(s): Homo sapiens
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2017-05-04 Released: 2017-09-06
  • Deposition Author(s): Yin, Z., Machius, M., Rudenko, G.
  • Funding Organization(s): National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA), Brain and Behavior Research Foundation

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:
    0.275 (Depositor), 0.268 (DCC)
  • R-Value Work:
    0.238 (Depositor), 0.233 (DCC)
  • R-Value Observed:
    0.241 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 5VPB

This is version 1.5 of the entry. See complete history

Literature

Activator Protein-1: redox switch controlling structure and DNA-binding.

Yin, Z.Machius, M.Nestler, E.J.Rudenko, G.

(2017) Nucleic Acids Res 45: 11425-11436

  • DOI: https://doi.org/10.1093/nar/gkx795
  • Primary Citation Related Structures:
    5VPA, 5VPB, 5VPC, 5VPD, 5VPE, 5VPF

  • PubMed Abstract:

    The transcription factor, activator protein-1 (AP-1), binds to cognate DNA under redox control; yet, the underlying mechanism has remained enigmatic. A series of crystal structures of the AP-1 FosB/JunD bZIP domains reveal ordered DNA-binding regions in both FosB and JunD even in absence DNA. However, while JunD is competent to bind DNA, the FosB bZIP domain must undergo a large conformational rearrangement that is controlled by a 'redox switch' centered on an inter-molecular disulfide bond. Solution studies confirm that FosB/JunD cannot undergo structural transition and bind DNA when the redox-switch is in the 'OFF' state, and show that the mid-point redox potential of the redox switch affords it sensitivity to cellular redox homeostasis. The molecular and structural studies presented here thus reveal the mechanism underlying redox-regulation of AP-1 Fos/Jun transcription factors and provide structural insight for therapeutic interventions targeting AP-1 proteins.


  • Organizational Affiliation
    • Department of Pharmacology and Toxicology, and the Sealy Center for Structural Biology, University of Texas Medical Branch, Galveston, TX 77555, USA.

Macromolecule Content

  • Total Structure Weight: 32.97 kDa
  • Atom Count: 1,940
  • Modeled Residue Count: 246
  • Deposited Residue Count: 272
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Protein fosBA [auth C],
C [auth A]
68Homo sapiensMutation(s): 0
Gene Names: FOSBG0S3
UniProt & NIH Common Fund Data Resources
Find proteins for P53539 (Homo sapiens)
Explore P53539
Go to UniProtKB:  P53539
PHAROS:  P53539
GTEx:  ENSG00000125740
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53539
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Transcription factor jun-DB [auth D],
D [auth B]
68Homo sapiensMutation(s): 0
Gene Names: JUND
UniProt & NIH Common Fund Data Resources
Find proteins for P17535 (Homo sapiens)
Explore P17535
Go to UniProtKB:  P17535
PHAROS:  P17535
GTEx:  ENSG00000130522
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP17535
Sequence Annotations
Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
CL

Query on CL



Download:Ideal Coordinates CCD File
E [auth D]
F [auth D]
G [auth D]
H [auth D]
I [auth A]
E [auth D],
F [auth D],
G [auth D],
H [auth D],
I [auth A],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth B],
O [auth B],
P [auth B],
Q [auth B]
CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.69 Å
  • R-Value Free:  0.275 (Depositor), 0.268 (DCC)
  • R-Value Work:  0.238 (Depositor), 0.233 (DCC)
  • R-Value Observed: 0.241 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 92.825α = 90
b = 99.261β = 109.4
c = 49.86γ = 90
Software Package:
Software NamePurpose
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
DENZOdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute on Drug Abuse (NIH/NIDA)United StatesR01 DA040621
Brain and Behavior Research FoundationUnited States--

Revision History  (Full details and data files)

  • Version 1.0: 2017-09-06
    Type: Initial release
  • Version 1.1: 2017-10-18
    Changes: Database references
  • Version 1.2: 2017-11-15
    Changes: Database references
  • Version 1.3: 2019-12-11
    Changes: Author supporting evidence
  • Version 1.4: 2023-10-04
    Changes: Data collection, Database references, Refinement description
  • Version 1.5: 2024-11-13
    Changes: Structure summary
