5Y44 | pdb_00005y44

A novel moderator XD4 for bile acid receptor

• PDB DOI: https://doi.org/10.2210/pdb5Y44/pdb

• Classification: TRANSCRIPTION/TRANSCRIPTION ACTIVATOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-08-01 Released: 2019-02-20
• Deposition Author(s): Lu, Y., Li, Y.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.35 Å
• R-Value Free:
  0.271 (Depositor), 0.270 (DCC)
• R-Value Work:
  0.198 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.202 (Depositor)

Literature

A novel moderator XD4 for bile acid receptor

Lu, Y., Li, Y.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 28.37 kDa
• Atom Count: 2,081
• Modeled Residue Count: 235
• Deposited Residue Count: 238
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bile acid receptor	A	227	Homo sapiens	Mutation(s): 0  Gene Names: NR1H4, BAR, FXR, HRR1, RIP14
UniProt & NIH Common Fund Data Resources
Find proteins for Q96RI1 (Homo sapiens) Explore Q96RI1  Go to UniProtKB:  Q96RI1
PHAROS:  Q96RI1 GTEx:  ENSG00000012504

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptide from Nuclear receptor coactivator 1	B	11	Homo sapiens	Mutation(s): 0  EC: 2.3.1.48
UniProt & NIH Common Fund Data Resources
Find proteins for Q15788 (Homo sapiens) Explore Q15788  Go to UniProtKB:  Q15788
PHAROS:  Q15788 GTEx:  ENSG00000084676

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
XD4	C [auth A]	[(1R,2R,4R)-1,7,7-trimethyl-2-bicyclo[2.2.1]heptanyl] 4-azanyl-3-methyl-benzoate C18 H25 N O2 GKVIGQZAEPCDNT-SIIHOXLZSA-N
SO4	D [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.35 Å
• R-Value Free:  0.271 (Depositor), 0.270 (DCC)
• R-Value Work:  0.198 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.202 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.678	α = 90
b = 161.49	β = 90
c = 115.762	γ = 90

Software Package:

Software Name	Purpose
HKL-2000	data scaling
REFMAC	refinement
PDB_EXTRACT	data extraction
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-02-20
Deposition Author(s): Lu, Y., Li, Y.

Revision History

• Version 1.0: 2019-02-20
  Type: Initial release

• Version 1.1: 2024-03-27
  Changes: Data collection, Database references
