5Y49 | pdb_00005y49

A moderator XD22 binding to bile acid receptor

• PDB DOI: https://doi.org/10.2210/pdb5Y49/pdb

• Classification: TRANSCRIPTION/TRANSCRIPTION ACTIVATOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2017-08-02 Released: 2019-02-20
• Deposition Author(s): Lu, Y., Li, Y.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:
  0.253 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.212 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.214 (Depositor)

Starting Model: experimental

Literature

A moderator XD22 binding to bile acid receptor

Lu, Y., Li, Y.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 2-mer - A1B1

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 56.34 kDa
• Atom Count: 4,030
• Modeled Residue Count: 472
• Deposited Residue Count: 476
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bile acid receptor	A, B	227	Homo sapiens	Mutation(s): 0  Gene Names: NR1H4, BAR, FXR, HRR1, RIP14
UniProt & NIH Common Fund Data Resources
Find proteins for Q96RI1 (Homo sapiens) Explore Q96RI1  Go to UniProtKB:  Q96RI1
PHAROS:  Q96RI1 GTEx:  ENSG00000012504

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptide from Nuclear receptor coactivator 2	C [auth D], D [auth E]	11	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for Q15596 (Homo sapiens) Explore Q15596  Go to UniProtKB:  Q15596
PHAROS:  Q15596 GTEx:  ENSG00000140396

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
XD5	E [auth A], F [auth B]	[(1R,2S,4S)-2-bicyclo[2.2.1]heptanyl] 4-azanylbenzoate C14 H17 N O2 GVFBCMCEUNYYSX-NDMJEZRESA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.40 Å
• R-Value Free:  0.253 (Depositor), 0.250 (DCC)
• R-Value Work:  0.212 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.214 (Depositor)

Space Group: P 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 73.805	α = 90
b = 34.853	β = 98.21
c = 117.305	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data scaling
PDB_EXTRACT	data extraction
REFMAC	refinement

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-02-20
Deposition Author(s): Lu, Y., Li, Y.

Revision History

• Version 1.0: 2019-02-20
  Type: Initial release

• Version 1.1: 2023-11-22
  Changes: Advisory, Data collection, Database references, Refinement description
