5YOU | pdb_00005you

Crystal structure of BRD4-BD1 bound with hjp64

PDB DOI: https://doi.org/10.2210/pdb5YOU/pdb

Classification: TRANSCRIPTION/INHIBITOR
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2017-10-31 Released: 2018-11-07
Deposition Author(s): Bing, X., Jianping, H., Yanlian, L., Danyan, C.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.248 (Depositor), 0.250 (DCC)
R-Value Work:
0.208 (Depositor), 0.210 (DCC)
R-Value Observed:
0.210 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of BRD4-BD1 bound with hjp64

Bing, X., Jianping, H., Yanlian, L., Danyan, C.

To be published.

Macromolecule Content

Total Structure Weight: 15.46 kDa
Atom Count: 1,134
Modeled Residue Count: 123
Deposited Residue Count: 127
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 4	A	127	Homo sapiens	Mutation(s): 1 Gene Names: BRD4, HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens) Explore O60885 Go to UniProtKB: O60885
PHAROS: O60885 GTEx: ENSG00000141867
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	O60885
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
8XX Query on 8XX Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(3~{R})-4-cyclopropyl-~{N},1,3-trimethyl-~{N}-(4-methylphenyl)-2-oxidanylidene-3~{H}-quinoxaline-6-carboxamide C₂₂ H₂₅ N₃ O₂ BFUVXHIKTHZHOZ-OAHLLOKOSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Binding Affinity Annotations
ID	Source	Binding Affinity
8XX	BindingDB: 5YOU	IC50: 11 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.248 (Depositor), 0.250 (DCC)
R-Value Work: 0.208 (Depositor), 0.210 (DCC)
R-Value Observed: 0.210 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 34.622	α = 90
b = 47.598	β = 90
c = 77.954	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
ADSC	data collection
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2018-11-07

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2018-11-07
Type: Initial release
Version 1.1: 2024-03-27
Changes: Data collection, Database references
