5ZXW

Crystal structure of human carbonic anhydrase II crystallized by ammonium sulfate

• PDB DOI: https://doi.org/10.2210/pdb5ZXW/pdb

• Classification: LYASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-05-22 Released: 2018-06-13
• Deposition Author(s): Kitahara, M., Fudo, S., Yoneda, T., Nukaga, M., Hoshino, T.
• Funding Organization(s): Japan Society for the Promotion of Science

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.32 Å
• R-Value Free:
  0.198 (Depositor), 0.200 (DCC)
• R-Value Work:
  0.171 (Depositor), 0.170 (DCC)
• R-Value Observed:
  0.172 (Depositor)

Starting Model: experimental

Literature

Anisotropic Distribution of Ammonium Sulfate Ions in Protein Crystallization

Kitahara, M., Fudo, S., Yoneda, T., Nukaga, M., Hoshino, T.

(2019) Cryst Growth Des 19: 6004-6010

• DOI: https://doi.org/10.1021/acs.cgd.9b00256

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 29.98 kDa
• Atom Count: 2,377
• Modelled Residue Count: 256
• Deposited Residue Count: 266
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbonic anhydrase 2	A	266	Homo sapiens	Mutation(s): 0  Gene Names: CA2 EC: 4.2.1.1 (PDB Primary Data), 4.2.1.69 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P00918 (Homo sapiens) Explore P00918  Go to UniProtKB:  P00918
PHAROS:  P00918 GTEx:  ENSG00000104267

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.32 Å
• R-Value Free:  0.198 (Depositor), 0.200 (DCC)
• R-Value Work:  0.171 (Depositor), 0.170 (DCC)
• R-Value Observed: 0.172 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.102	α = 90
b = 41.323	β = 104.19
c = 72.13	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
Aimless	data scaling
MOLREP	phasing
PHENIX	refinement
PDB_EXTRACT	data extraction

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2018-06-13
Deposition Author(s): Kitahara, M., Fudo, S., Yoneda, T., Nukaga, M., Hoshino, T.

---

Funding Organization	Location	Grant Number
Japan Society for the Promotion of Science	Japan	15K08458

Revision History

• Version 1.0: 2018-06-13
  Type: Initial release

• Version 1.1: 2019-11-20
  Changes: Database references
• Version 1.2: 2023-11-22
  Changes: Data collection, Database references, Refinement description
