6CUB

Structure of human DNA polymerase beta complexed with 8-ClG in the template base paired with incoming non-hydrolyzable ATP and MANGANESE

• PDB DOI: https://doi.org/10.2210/pdb6CUB/pdb
• NAKB: 6CUB

• Classification: Transferase, Lyase/DNA
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2018-03-25 Released: 2019-03-27
• Deposition Author(s): Koag, M.-C., Lee, S.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:
  0.254 (Depositor), 0.250 (DCC)
• R-Value Work:
  0.197 (Depositor), 0.200 (DCC)
• R-Value Observed:
  0.200 (Depositor)

Literature

Structure of human DNA polymerase beta complexed with 8-ClG in the template base paired with incoming non-hydrolyzable ATP and MANGANESE

Koag, M.-C., Lee, S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 48.39 kDa
• Atom Count: 3,450
• Modelled Residue Count: 358
• Deposited Residue Count: 366
• Unique protein chains: 1
• Unique nucleic acid chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
DNA polymerase beta	A	335	Homo sapiens	Mutation(s): 0  Gene Names: POLB EC: 2.7.7.7 (PDB Primary Data), 4.2.99 (PDB Primary Data), 4.2.99.18 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P06746 (Homo sapiens) Explore P06746  Go to UniProtKB:  P06746
PHAROS:  P06746 GTEx:  ENSG00000070501

Entity ID: 2
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*CP*CP*GP*AP*CP*(CGM)P*TP*CP*GP*CP*AP*TP*CP*AP*GP*C)-3')	B [auth T]	16	Homo sapiens

Entity ID: 3
Molecule	Chains	Length	Organism	Image
DNA (5'-D(*GP*CP*TP*GP*AP*TP*GP*CP*GP*A)-3')	C [auth P]	10	Homo sapiens

Entity ID: 4
Molecule	Chains	Length	Organism	Image
DNA (5'-D(P*GP*TP*CP*GP*G)-3')	D	5	Homo sapiens

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
DZ4	E [auth A]	2'-deoxy-5'-O-[(R)-hydroxy{[(R)-hydroxy(phosphonooxy)phosphoryl]amino}phosphoryl]adenosine C10 H17 N6 O11 P3 WKIPJDSLGCBQCU-RRKCRQDMSA-N
MN	F [auth A], G [auth A]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N
NA	H [auth A], I [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.05 Å
• R-Value Free:  0.254 (Depositor), 0.250 (DCC)
• R-Value Work:  0.197 (Depositor), 0.200 (DCC)
• R-Value Observed: 0.200 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 54.786	α = 90
b = 78.993	β = 105.91
c = 54.771	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2019-03-27
Deposition Author(s): Koag, M.-C., Lee, S.

Revision History

• Version 1.0: 2019-03-27
  Type: Initial release

• Version 1.1: 2024-03-13
  Changes: Data collection, Database references, Derived calculations
