6GJO | pdb_00006gjo

Crystal Structure of Glycogen Synthase Kinase-3 beta in Complex with BI-91BS

PDB DOI: https://doi.org/10.2210/pdb6GJO/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2018-05-16 Released: 2019-03-27
Deposition Author(s): Hoerer, S.

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.91 Å
R-Value Free:
0.237 (Depositor), 0.240 (DCC)
R-Value Work:
0.217 (Depositor), 0.230 (DCC)
R-Value Observed:
0.218 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

CRYSTAL STRUCTURE OF Glycogen synthase kinase-3 beta IN COMPLEX WITH BI-91BS

Hoerer, S.

To be published.

Macromolecule Content

Total Structure Weight: 92.98 kDa
Atom Count: 5,648
Modeled Residue Count: 692
Deposited Residue Count: 828
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycogen synthase kinase-3 beta	A, B	414	Homo sapiens	Mutation(s): 0 Gene Names: GSK3B EC: 2.7.11.26 (PDB Primary Data), 2.7.11.1 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P49841 (Homo sapiens) Explore P49841 Go to UniProtKB: P49841
PHAROS: P49841 GTEx: ENSG00000082701
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P49841
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
F1B (Subject of Investigation/LOI) Query on F1B Download Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	(3~{Z})-5-ethanoyl-3-[[(1-methylpiperidin-4-yl)amino]-phenyl-methylidene]-1~{H}-indol-2-one C₂₃ H₂₅ N₃ O₂ WPYXXIHXRUGCDD-DQRAZIAOSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.91 Å
R-Value Free: 0.237 (Depositor), 0.240 (DCC)
R-Value Work: 0.217 (Depositor), 0.230 (DCC)
R-Value Observed: 0.218 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.712	α = 77.51
b = 67.484	β = 77.56
c = 67.787	γ = 89.21

Software Package:

Software Name	Purpose
BUSTER	refinement
MOSFLM	data reduction
SCALA	data scaling
AMoRE	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2019-03-27

Deposition Author(s):

Revision History (Full details and data files)

Version 1.0: 2019-03-27
Type: Initial release
Version 1.1: 2024-05-15
Changes: Data collection, Database references
