6HRP

CRYSTAL STRUCTURE OF BTK KINASE DOMAIN COMPLEXED WITH 6-(dimethylamino)-2-[2-(hydroxymethyl)-3-[1-methyl-5-[[5-(morpholine-4-carbonyl)-2-pyridyl]amino]-6-oxo-3-pyridyl]phenyl]-3,4-dihydroisoquinolin-1-one


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.12 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.174
  • R-Value Observed: 0.175

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

A potent seven-membered cyclic BTK (Bruton's tyrosine Kinase) chiral inhibitor conceived by structure-based drug design to lock its bioactive conformation.

Lopez-Tapia, F.Lou, Y.Brotherton-Pleiss, C.Kuglstatter, A.So, S.S.Kondru, R.

(2019) Bioorg Med Chem Lett 29: 1074-1078

  • DOI: https://doi.org/10.1016/j.bmcl.2019.03.001
  • Primary Citation of Related Structures:
    6HRP, 6HRT

  • PubMed Abstract:

    A seven-membered cyclic chiral analog of potent lead BTK inhibitor 1 was envisioned by structure-based design to lock the molecule into its bioactive conformation. For the elaboration of the seven-membered ring, compound 1 pyridone 6-position was substituted with the purpose to prevent formation of reactive metabolites. Eventually, the cyclic chiral compound 3 maintained the high potency of 1, and most importantly showed no activity at either GSH or TDI assays suggesting no formation of reactive metabolites. The anticipated bound conformation of 3 to BTK was confirmed by X-ray crystallography. Synthetically, the crucial seven-membered ring formation was obtained by using TosMIC as a connective reagent.


  • Organizational Affiliation

    Hoffmann-La Roche Ltd., pRED, Pharma Research & Early Development, 340 Kingsland Street, Nutley 07110, United States. Electronic address: ftapia@cc.hawaii.edu.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tyrosine-protein kinase BTK283Homo sapiensMutation(s): 4
Gene Names: BTKAGMX1ATKBPK
EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for Q06187 (Homo sapiens)
Explore Q06187
Go to UniProtKB:  Q06187
PHAROS:  Q06187
GTEx:  ENSG00000010671
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ06187
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
GMQ (Subject of Investigation/LOI)
Query on GMQ

Download Ideal Coordinates CCD File
B [auth A]6-~{tert}-butyl-8-fluoranyl-2-[2-(hydroxymethyl)-3-[1-methyl-5-[(5-morpholin-4-ylcarbonylpyridin-2-yl)amino]-6-oxidanylidene-pyridazin-3-yl]phenyl]phthalazin-1-one
C34 H34 F N7 O5
GLLQSOROVXWYRC-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.12 Å
  • R-Value Free: 0.192
  • R-Value Work: 0.174
  • R-Value Observed: 0.175
  • Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 71.805α = 90
b = 106.969β = 90
c = 38.299γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
SCALAdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-03-20
    Type: Initial release
  • Version 1.1: 2019-04-03
    Changes: Data collection, Database references
  • Version 1.2: 2019-05-15
    Changes: Data collection, Refinement description
