6JYT

Delicate structural coordination of the Severe Acute Respiratory Syndrome coronavirus Nsp13 upon ATP hydrolysis


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.292
  • R-Value Work: 0.237
  • R-Value Observed: 0.240

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Delicate structural coordination of the Severe Acute Respiratory Syndrome coronavirus Nsp13 upon ATP hydrolysis.

Jia, Z.Yan, L.Ren, Z.Wu, L.Wang, J.Guo, J.Zheng, L.Ming, Z.Zhang, L.Lou, Z.Rao, Z.

(2019) Nucleic Acids Res 47: 6538-6550

  • DOI: https://doi.org/10.1093/nar/gkz409
  • Primary Citation of Related Structures:
    6JYT

  • PubMed Abstract:

    To date, an effective therapeutic treatment that confers strong attenuation toward coronaviruses (CoVs) remains elusive. Of all the potential drug targets, the helicase of CoVs is considered to be one of the most important. Here, we first present the structure of the full-length Nsp13 helicase of SARS-CoV (SARS-Nsp13) and investigate the structural coordination of its five domains and how these contribute to its translocation and unwinding activity. A translocation model is proposed for the Upf1-like helicase members according to three different structural conditions in solution characterized through H/D exchange assay, including substrate state (SARS-Nsp13-dsDNA bound with AMPPNP), transition state (bound with ADP-AlF4-) and product state (bound with ADP). We observed that the β19-β20 loop on the 1A domain is involved in unwinding process directly. Furthermore, we have shown that the RNA dependent RNA polymerase (RdRp), SARS-Nsp12, can enhance the helicase activity of SARS-Nsp13 through interacting with it directly. The interacting regions were identified and can be considered common across CoVs, which provides new insights into the Replication and Transcription Complex (RTC) of CoVs.


  • Organizational Affiliation

    Laboratory of Structural Biology, School of Medicine, Tsinghua University, Beijing 100084, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Helicase
A, B
603Severe acute respiratory syndrome-related coronavirusMutation(s): 0
Gene Names: rep1a-1b
EC: 3.6.4.12 (PDB Primary Data), 3.6.4.13 (PDB Primary Data)
UniProt
Find proteins for P0C6X7 (Severe acute respiratory syndrome coronavirus)
Explore P0C6X7
Go to UniProtKB:  P0C6X7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C6X7
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.80 Å
  • R-Value Free: 0.292
  • R-Value Work: 0.237
  • R-Value Observed: 0.240
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 191.99α = 90
b = 189.15β = 102.89
c = 57.33γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
HKL-3000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (China)China2017YFC0840302

Revision History  (Full details and data files)

  • Version 1.0: 2019-09-18
    Type: Initial release
  • Version 1.1: 2024-10-09
    Changes: Data collection, Database references, Derived calculations, Structure summary
