6PLG

Crystal structure of human PHGDH complexed with Compound 15


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.93 Å
  • R-Value Free: 0.315
  • R-Value Work: 0.274
  • R-Value Observed: 0.276

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.3 of the entry. See complete history


Literature

Inhibition of 3-phosphoglycerate dehydrogenase (PHGDH) by indole amides abrogates de novo serine synthesis in cancer cells.

Mullarky, E.Xu, J.Robin, A.D.Huggins, D.J.Jennings, A.Noguchi, N.Olland, A.Lakshminarasimhan, D.Miller, M.Tomita, D.Michino, M.Su, T.Zhang, G.Stamford, A.W.Meinke, P.T.Kargman, S.Cantley, L.C.

(2019) Bioorg Med Chem Lett 29: 2503-2510

  • DOI: https://doi.org/10.1016/j.bmcl.2019.07.011
  • Primary Citation of Related Structures:
    6PLF, 6PLG

  • PubMed Abstract:

    Cancer cells reprogram their metabolism to support growth and to mitigate cellular stressors. The serine synthesis pathway has been identified as a metabolic pathway frequently altered in cancers and there has been considerable interest in developing pharmacological agents to target this pathway. Here, we report a series of indole amides that inhibit human 3-phosphoglycerate dehydrogenase (PHGDH), the enzyme that catalyzes the first committed step of the serine synthesis pathway. Using X-ray crystallography, we show that the indole amides bind the NAD + pocket of PHGDH. Through structure-based optimization we were able to develop compounds with low nanomolar affinities for PHGDH in an enzymatic IC 50 assay. In cellular assays, the most potent compounds inhibited de novo serine synthesis with low micromolar to sub-micromolar activities and these compounds successfully abrogated the proliferation of cancer cells in serine free media. The indole amide series reported here represent an important improvement over previously published PHGDH inhibitors as they are markedly more potent and their mechanism of action is better defined.


  • Organizational Affiliation

    Meyer Cancer Center, Weill Cornell Medical College, New York, NY 10065, United States; Department of Medicine, Weill Cornell Medical College, New York, NY 10065, United States. Electronic address: edm2015@med.cornell.edu.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
D-3-phosphoglycerate dehydrogenase
A, B, C, D, E
A, B, C, D, E, F, G, H
314Homo sapiensMutation(s): 0
Gene Names: PHGDHPGDH3
EC: 1.1.1.95 (PDB Primary Data), 1.1.1.399 (PDB Primary Data), 1.1.1.37 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for O43175 (Homo sapiens)
Explore O43175
Go to UniProtKB:  O43175
PHAROS:  O43175
GTEx:  ENSG00000092621
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO43175
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ONS (Subject of Investigation/LOI)
Query on ONS

Download Ideal Coordinates CCD File
I [auth A]
J [auth B]
K [auth C]
L [auth D]
M [auth E]
I [auth A],
J [auth B],
K [auth C],
L [auth D],
M [auth E],
O [auth F],
Q [auth G],
S [auth H]
(2S)-(4-{3-[(4,5-dichloro-1-methyl-1H-indole-2-carbonyl)amino]oxetan-3-yl}phenyl)(pyridin-3-yl)acetic acid
C26 H21 Cl2 N3 O4
LHTXTAIWLHZCIX-QFIPXVFZSA-N
MLT
Query on MLT

Download Ideal Coordinates CCD File
N [auth E],
P [auth F],
R [auth G],
T [auth H]
D-MALATE
C4 H6 O5
BJEPYKJPYRNKOW-UWTATZPHSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.93 Å
  • R-Value Free: 0.315
  • R-Value Work: 0.274
  • R-Value Observed: 0.276
  • Space Group: P 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 44.649α = 105.98
b = 112.699β = 96.2
c = 137.84γ = 101.42
Software Package:
Software NamePurpose
SCALEPACKdata scaling
REFMACrefinement
PDB_EXTRACTdata extraction
HKL-2000data reduction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-07-24
    Type: Initial release
  • Version 1.1: 2019-08-07
    Changes: Data collection, Database references
  • Version 1.2: 2019-09-04
    Changes: Data collection, Database references
  • Version 1.3: 2024-11-06
    Changes: Data collection, Database references, Refinement description, Structure summary
