6SM5

MbC/SHP1-C-SH2 complex

PDB DOI: https://doi.org/10.2210/pdb6SM5/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Homo sapiens, synthetic construct
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2019-08-21 Released: 2021-01-13
Deposition Author(s): Mann, G., Hantschel, O.
Funding Organization(s): European Research Council

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.75 Å
R-Value Free: 0.276
R-Value Work: 0.219
R-Value Observed: 0.225

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

MbC/SHP1-C-SH2 complex

Hantschel, O.

To be published.

Macromolecule Content

Total Structure Weight: 23.26 kDa
Atom Count: 1,557
Modelled Residue Count: 197
Deposited Residue Count: 213
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Tyrosine-protein phosphatase non-receptor type 6	A	120	Homo sapiens	Mutation(s): 0 Gene Names: PTPN6, HCP, PTP1C EC: 3.1.3.48
UniProt & NIH Common Fund Data Resources
Find proteins for P29350 (Homo sapiens) Explore P29350 Go to UniProtKB: P29350
PHAROS: P29350 GTEx: ENSG00000111679
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P29350
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
MbC (monobody targeting SHP1-C-SH2)	B	93	synthetic construct	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.75 Å
R-Value Free: 0.276
R-Value Work: 0.219
R-Value Observed: 0.225
Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.898	α = 90
b = 63.82	β = 90
c = 73.101	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2021-01-13

Deposition Author(s):

Funding Organization	Location	Grant Number
European Research Council		--

Revision History (Full details and data files)

Version 1.0: 2021-01-13
Type: Initial release
Version 1.1: 2024-01-24
Changes: Data collection, Database references, Refinement description
