6SZE | pdb_00006sze

RIP2 Kinase Catalytic Domain complex with 5-Amino-1-Phenylpyrazole-4-Carboxamide.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:
    0.234 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.176 (Depositor), 0.177 (DCC)
  • R-Value Observed:
    0.179 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 6SZE

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

Discovery of Pyrazolocarboxamides as Potent and Selective Receptor Interacting Protein 2 (RIP2) Kinase Inhibitors.

Haffner, C.D.Charnley, A.K.Aquino, C.J.Casillas, L.Convery, M.A.Cox, J.A.Elban, M.A.Goodwin, N.C.Gough, P.J.Haile, P.A.Hughes, T.V.Knapp-Reed, B.Kreatsoulas, C.Lakdawala, A.S.Li, H.Lian, Y.Lipshutz, D.Mehlmann, J.F.Ouellette, M.Romano, J.Shewchuk, L.Shu, A.Votta, B.J.Zhou, H.Bertin, J.Marquis, R.W.

(2019) ACS Med Chem Lett 10: 1518-1523

  • DOI: https://doi.org/10.1021/acsmedchemlett.9b00141
  • Primary Citation Related Structures:
    6SZE, 6SZJ, 6UL8

  • PubMed Abstract:

    Herein we report the discovery of pyrazolocarboxamides as novel, potent, and kinase selective inhibitors of receptor interacting protein 2 kinase (RIP2). Fragment based screening and design principles led to the identification of the inhibitor series, and X-ray crystallography was used to inform key structural changes. Through key substitutions about the N1 and C5 N positions on the pyrazole ring significant kinase selectivity and potency were achieved. Bridged bicyclic pyrazolocarboxamide 11 represents a selective and potent inhibitor of RIP2 and will allow for a more detailed investigation of RIP2 inhibition as a therapeutic target for autoinflammatory disorders.


  • Organizational Affiliation
    • GlaxoSmithKline, 1250 South Collegeville Road, Collegeville, Pennsylvania 19426, United States.

Macromolecule Content

  • Total Structure Weight: 71.81 kDa
  • Atom Count: 4,646
  • Modeled Residue Count: 550
  • Deposited Residue Count: 622
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Receptor-interacting serine/threonine-protein kinase 2
A, B
311Homo sapiensMutation(s): 0
EC: 2.7.11.1 (PDB Primary Data), 2.7.10.2 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for O43353 (Homo sapiens)
Explore O43353
Go to UniProtKB:  O43353
PHAROS:  O43353
GTEx:  ENSG00000104312
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO43353
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.94 Å
  • R-Value Free:  0.234 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.176 (Depositor), 0.177 (DCC)
  • R-Value Observed: 0.179 (Depositor)
Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 131.66α = 90
b = 131.66β = 90
c = 107.084γ = 120
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
MOSFLMdata reduction
SCALAdata scaling
REFMACphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2019-10-23
    Type: Initial release
  • Version 1.1: 2019-12-04
    Changes: Database references
  • Version 1.2: 2024-05-15
    Changes: Data collection, Database references
