6ULJ | pdb_00006ulj

Crystal structure of human GAC in complex with inhibitor UPGL00012

• PDB DOI: https://doi.org/10.2210/pdb6ULJ/pdb

• Classification: HYDROLASE/HYDROLASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2019-10-08 Released: 2020-10-14
• Deposition Author(s): Huang, Q., Cerione, R.A.
• Funding Organization(s): National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.69 Å
• R-Value Free:
  0.236 (Depositor)
• R-Value Work:
  0.178 (Depositor)
• R-Value Observed:
  0.180 (Depositor)

Starting Model: experimental

Literature

Crystal structure of human GAC in complex with inhibitor UPGL00045

Huang, Q., Cerione, R.A.

To be published.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 233.14 kDa
• Atom Count: 13,032
• Modeled Residue Count: 1,639
• Deposited Residue Count: 2,108
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutaminase kidney isoform, mitochondrial	A, B, C, D	527	Homo sapiens	Mutation(s): 0  Gene Names: GLS, GLS1, KIAA0838 EC: 3.5.1.2
UniProt & NIH Common Fund Data Resources
Find proteins for O94925 (Homo sapiens) Explore O94925  Go to UniProtKB:  O94925
PHAROS:  O94925 GTEx:  ENSG00000115419

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
QAA (Subject of Investigation/LOI)	E [auth B], F [auth C]	2-phenyl-N-{6-[4-({6-[(phenylacetyl)amino]pyridazin-3-yl}oxy)piperidin-1-yl]pyridazin-3-yl}acetamide C29 H29 N7 O3 IDGBGPKCEIHLHR-UHFFFAOYSA-N

Binding Affinity Annotations
ID	Source	Binding Affinity
QAA	BindingDB:  6ULJ	IC50: 98 (nM) from 1 assay(s)

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.69 Å
• R-Value Free:  0.236 (Depositor)
• R-Value Work:  0.178 (Depositor)
• R-Value Observed: 0.180 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.55	α = 90
b = 138.888	β = 93.914
c = 176.993	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHENIX	phasing

Structure Validation

Currently 6ULJ does not have a validation slider image.

Entry History & Funding Information

Deposition Data

• Released Date: 2020-10-14
Deposition Author(s): Huang, Q., Cerione, R.A.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)	United States	GM122575
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)	United States	GM124166
National Institutes of Health/National Human Genome Research Institute (NIH/NHGRI)	United States	CA201402

Revision History

• Version 1.0: 2020-10-14
  Type: Initial release

• Version 1.1: 2023-10-11
  Changes: Advisory, Data collection, Database references, Refinement description
