6VWU

X-ray structure of ALKS 4230, a fusion of circularly permuted human Interleukin-2 and Interleukin-2 Receptor alpha


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free: 0.297
  • R-Value Work: 0.275
  • R-Value Observed: 0.277

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report

Currently 6VWU does not have a validation slider image.


This is version 1.3 of the entry. See complete history


Literature

ALKS 4230: a novel engineered IL-2 fusion protein with an improved cellular selectivity profile for cancer immunotherapy.

Lopes, J.E.Fisher, J.L.Flick, H.L.Wang, C.Sun, L.Ernstoff, M.S.Alvarez, J.C.Losey, H.C.

(2020) J Immunother Cancer 8

  • DOI: https://doi.org/10.1136/jitc-2020-000673
  • Primary Citation of Related Structures:
    6VWU

  • PubMed Abstract:

    Interleukin-2 (IL-2) plays a pivotal role in immune homeostasis due to its ability to stimulate numerous lymphocyte subsets including natural killer (NK) cells, effector CD4 + and CD8 + T cells, and regulatory T cells (T regs ). Low concentrations of IL-2 induce signaling through the high-affinity IL-2 receptor (IL-2R) comprised of IL-2Rα, IL-2Rβ, and common γ chain (γ c ), preferentially expressed on T regs . Higher concentrations of IL-2 are necessary to induce signaling through the intermediate-affinity IL-2R, composed of IL-2Rβ and γ c , expressed on memory CD8 + T cells and NK cells. Recombinant human IL-2 (rhIL-2) is approved for treatment of metastatic melanoma and renal cell carcinoma (RCC), but adverse events including capillary leak syndrome, potentially mediated through interaction with the high-affinity IL-2R, limit its therapeutic use. Furthermore, antitumor efficacy of IL-2 may also be limited by preferential expansion of immunosuppressive T regs . ALKS 4230 is an engineered fusion protein comprised of a circularly-permuted IL-2 with the extracellular domain of IL-2Rα, designed to selectively activate effector lymphocytes bearing the intermediate-affinity IL-2R. ALKS 4230 was equipotent to rhIL-2 in activating human cells bearing the intermediate-affinity IL-2R, and less potent than rhIL-2 on cells bearing the high-affinity IL-2R. As observed in vitro with primary human cells from healthy donors and advanced cancer patients, ALKS 4230 induced greater activation and expansion of NK cells with reduced expansion of T regs relative to rhIL-2. Similarly, in mice, ALKS 4230 treatment stimulated greater expansion of NK cells and memory-phenotype CD8 + T cells at doses that did not expand or activate T regs . ALKS 4230 treatment induced significantly lower levels of proinflammatory cytokines, including tumor necrosis factor alpha, interleukin-6, and interferon gamma relative to rhIL-2. Furthermore, ALKS 4230 exhibited superior antitumor efficacy in the mouse B16F10 lung tumor model, where ALKS 4230 could be administered via multiple routes of administration and dosing schedules while achieving equivalent antitumor efficacy. ALKS 4230 exhibited enhanced pharmacokinetic and selective pharmacodynamic properties resulting in both improved antitumor efficacy and lower indices of toxicity relative to rhIL-2 in mice. These data highlight the potential of ALKS 4230 as a novel cancer immunotherapy, and as such, the molecule is being evaluated clinically.


  • Organizational Affiliation

    Research, Alkermes, Inc, Waltham, Massachusetts, USA.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Interleukin-2,Interleukin-2 receptor subunit alpha303Homo sapiensMutation(s): 0
Gene Names: IL2IL2RA
UniProt & NIH Common Fund Data Resources
Find proteins for P01589 (Homo sapiens)
Explore P01589
Go to UniProtKB:  P01589
PHAROS:  P01589
GTEx:  ENSG00000134460
Find proteins for P60568 (Homo sapiens)
Explore P60568
Go to UniProtKB:  P60568
PHAROS:  P60568
GTEx:  ENSG00000109471
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsP01589P60568
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.40 Å
  • R-Value Free: 0.297
  • R-Value Work: 0.275
  • R-Value Observed: 0.277
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 86.809α = 90
b = 86.809β = 90
c = 119.576γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report

Currently 6VWU does not have a validation slider image.



Entry History

Deposition Data

  • Released Date: 2020-04-29
  • Deposition Author(s): Losey, H.C.

Revision History  (Full details and data files)

  • Version 1.0: 2020-04-29
    Type: Initial release
  • Version 1.1: 2020-05-06
    Changes: Database references
  • Version 1.2: 2023-10-11
    Changes: Data collection, Database references, Refinement description
  • Version 1.3: 2024-11-20
    Changes: Structure summary
