8RJI

HLA A*2402-NF9_5R pMHC complex

• PDB DOI: https://doi.org/10.2210/pdb8RJI/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Homo sapiens, Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-12-21 Released: 2025-01-01
• Deposition Author(s): Wall, A., Motozono, C., Sewell, A.K., Rizkallah, P.J., Fuller, A.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:
  0.265 (Depositor), 0.263 (DCC)
• R-Value Work:
  0.217 (Depositor), 0.221 (DCC)
• R-Value Observed:
  0.219 (Depositor)

Literature

HLA A*2402-NF9_5R pMHC complex

Wall, A., Motozono, C., Sewell, A.K., Rizkallah, P.J., Fuller, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 2 assigned by authors and generated by PISA (software)

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 3 assigned by authors and generated by PISA (software)

Biological Assembly 4

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 4 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 179.87 kDa
• Atom Count: 13,033
• Modelled Residue Count: 1,540
• Deposited Residue Count: 1,540
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
MHC class I antigen	A, D, G, I [auth J]	276	Homo sapiens	Mutation(s): 0  Gene Names: HLA-A
UniProt
Find proteins for A0A411J078 (Homo sapiens) Explore A0A411J078  Go to UniProtKB:  A0A411J078

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-2-microglobulin	B, E, H, J [auth K]	100	Homo sapiens	Mutation(s): 0  Gene Names: B2M, CDABP0092, HDCMA22P
UniProt & NIH Common Fund Data Resources
Find proteins for P61769 (Homo sapiens) Explore P61769  Go to UniProtKB:  P61769
PHAROS:  P61769 GTEx:  ENSG00000166710

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	C, F, K [auth L], L [auth I]	9	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2  Go to UniProtKB:  P0DTC2

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.30 Å
• R-Value Free:  0.265 (Depositor), 0.263 (DCC)
• R-Value Work:  0.217 (Depositor), 0.221 (DCC)
• R-Value Observed: 0.219 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 103.281	α = 90
b = 77.018	β = 110.58
c = 111.82	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
PHASER	phasing
DIALS	data reduction

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-01-01
Deposition Author(s): Wall, A., Motozono, C., Sewell, A.K., Rizkallah, P.J., Fuller, A.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-01-01
  Type: Initial release
