9QA9 | pdb_00009qa9

Lysozyme in-situ room temperature

PDB DOI: https://doi.org/10.2210/pdb9QA9/pdb

Classification: HYDROLASE
Organism(s): Gallus gallus
Mutation(s): No

Deposited: 2025-02-27 Released: 2026-09-09
Deposition Author(s): Sirigu, S.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.56 Å
R-Value Free:
0.250 (Depositor), 0.231 (DCC)
R-Value Work:
0.236 (Depositor), 0.216 (DCC)
R-Value Observed:
0.237 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 9QA9

This is version 1.0 of the entry. See complete history.

Literature

Lysozyme in-situ room temperature

Sirigu, S.

To be published.

Macromolecule Content

Total Structure Weight: 14.4 kDa
Atom Count: 1,078
Modeled Residue Count: 129
Deposited Residue Count: 129
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysozyme C	A	129	Gallus gallus	Mutation(s): 0 EC: 3.2.1.17
UniProt
Find proteins for P00698 (Gallus gallus) Explore P00698 Go to UniProtKB: P00698
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P00698
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.56 Å
R-Value Free: 0.250 (Depositor), 0.231 (DCC)
R-Value Work: 0.236 (Depositor), 0.216 (DCC)
R-Value Observed: 0.237 (Depositor)

Space Group: P 4₃ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 79.24	α = 90
b = 79.24	β = 90
c = 38.01	γ = 90

Software Package:

Software Name	Purpose
BUSTER	refinement
XSCALE	data scaling
XDS	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-09-09

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded	France	--

Revision History (Full details and data files)

Version 1.0: 2026-09-09
Type: Initial release
