9QI9 | pdb_00009qi9

Crystal structure of styrene monooxygenase RhStyA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:
    0.197 (Depositor), 0.195 (DCC)
  • R-Value Work:
    0.170 (Depositor), 0.170 (DCC)
  • R-Value Observed:
    0.172 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Biocatalytic Activation of Sulfur Heteroaromatics Facilitates Dearomatizing Cross-Couplings to Set Stereogenic Centers or Axes.

Conboy, O.Rushworth, E.Q.Taylor, C.J.Levy, C.W.Ortmayer, M.Whitehead, G.F.S.Yen, A.Romano, C.Green, A.P.Procter, D.J.

(2025) J Am Chem Soc 147: 43057-43066

  • DOI: https://doi.org/10.1021/jacs.5c16261
  • Primary Citation of Related Structures:
    9QI9

  • PubMed Abstract:

    The enantioselective manipulation of abundant flat (hetero)aromatic building blocks through either dearomatization, to establish new stereocenters, or cross-coupling, to construct a stereogenic axis, is an attractive means to generate three-dimensional molecular architectures. By merging the selectivity of engineered biocatalysts with the versatility of chemical synthesis, we establish a new platform for the metal-free enantioselective manipulation of sulfur-containing heteroaromatics, allowing either point or axial chirality to be set. The key to this approach is our ability to leverage the prochirality of sulfur heteroarenes; biocatalytic oxidation of benzothiophenes "switches on" reactivity and establishes a sulfur stereocenter that directs the stereochemical course of subsequent cross-couplings with non-prefunctionalized partners. Exploiting a previously unexplored mechanism, either point-to-point or point-to-axial chirality transfer from sulfur selectively delivers two different sets of chiral molecules. Enzyme evolution is used to convert a wild-type oxygenase into an efficient and selective engineered S -oxygenase capable of furnishing enantiopure benzothiophene S -oxides─little-known sulfoxides whose configurational stability we map out. Our integrated chemoenzymatic approach provides a blueprint for unlocking the potential of sulfur chirality, lying dormant in important heterocycles, to direct transformations that deliver diverse enantioenriched products.


  • Organizational Affiliation
    • Department of Chemistry, University of Manchester, Oxford Road, Manchester M13 9PL, United Kingdom.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Styrene monooxygenase446RhodococcusMutation(s): 0
Gene Names: styA
UniProt
Find proteins for G3XEX2 (Rhodococcus sp. ST-10)
Explore G3XEX2
Go to UniProtKB:  G3XEX2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupG3XEX2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.80 Å
  • R-Value Free:  0.197 (Depositor), 0.195 (DCC)
  • R-Value Work:  0.170 (Depositor), 0.170 (DCC)
  • R-Value Observed: 0.172 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 46.008α = 90
b = 66.216β = 92.409
c = 68.713γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
DIALSdata reduction
xia2data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Engineering and Physical Sciences Research CouncilUnited KingdomEP/S023755/1

Revision History  (Full details and data files)

  • Version 1.0: 2026-01-28
    Type: Initial release
