9RLW | pdb_00009rlw

Leishmania major N-myristoyltransferase in complex with azetidinopyrimidine inhibitor IMP-825

• PDB DOI: https://doi.org/10.2210/pdb9RLW/pdb

• Classification: TRANSFERASE
• Organism(s): Leishmania major
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2025-06-17 Released: 2026-05-27
• Deposition Author(s): Brannigan, J.A.
• Funding Organization(s): Wellcome Trust

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.49 Å
• R-Value Free:
  0.227 (Depositor), 0.227 (DCC)
• R-Value Work:
  0.185 (Depositor), 0.185 (DCC)

Literature

Leishmania major N-myristoyltransferase in complex with azetidinopyrimidine inhibitor IMP-825

Bell, A.S.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 49.62 kDa
• Atom Count: 4,038
• Modeled Residue Count: 411
• Deposited Residue Count: 418
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glycylpeptide N-tetradecanoyltransferase	A	418	Leishmania major	Mutation(s): 0  Gene Names: NMT, LMJF_32_0080 EC: 2.3.1.97
UniProt
Find proteins for Q4Q5S8 (Leishmania major) Explore Q4Q5S8  Go to UniProtKB:  Q4Q5S8

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
MYA	D [auth A]	TETRADECANOYL-COA C35 H62 N7 O17 P3 S DUAFKXOFBZQTQE-QSGBVPJFSA-N
A1JHF( Subject of Investigation/LOI)	C [auth A]	~{N}-[[2,4-bis(fluoranyl)phenyl]methyl]-1-[5-chloranyl-2-[2-(dimethylamino)ethylamino]pyrimidin-4-yl]azetidine-3-carboxamide C19 H23 Cl F2 N6 O ALMPYYUVDQUXFO-UHFFFAOYSA-N
MG	B [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.49 Å
• R-Value Free:  0.227 (Depositor), 0.227 (DCC)
• R-Value Work:  0.185 (Depositor), 0.185 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.366	α = 90
b = 91.721	β = 112.923
c = 53.552	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
SCALA	data scaling
REFMAC	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-05-27
Deposition Author(s): Brannigan, J.A.

---

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	--

Revision History

• Version 1.0: 2026-05-27
  Type: Initial release
